Hyundai Azera 2014 Electrical Diagrams V6-3.3L

Description

• Model List:
  • Azera

• 1. Air Conditioning – Automatic A_C Circuit
• 2. Anti-Lock Brakes – W_ ESC
• 3. Anti-Lock Brakes – W_O ESC
• 4. Anti-Theft – Forced Entry Circuit
• 5. Anti-Theft – Immobilizer Circuit (W_ Smart Key System)
• 6. Anti-Theft – Immobilizer Circuit (W_O Smart Key System)
• 7. Body Computer
• 8. Computer Data Lines
• 9. Cooling Fans
• 10. Cruise Control
• 11. Defogger – W_ Auto Defogger
• 12. Defogger – W_O Auto Defogger
• 13. Door Locks
• 14. Electronic Power Steering – Electronic Power Steering Circuit
• 15. Electronic Power Steering – Power Tilt Steering Column Circuit
• 16. Engine Controls
• 17. Exterior Lights – Backup Lamps Circuit
• 18. Exterior Lights – Exterior Lamps Circuit (W_ ESC)
• 19. Exterior Lights – Exterior Lamps Circuit (W_O ESC)
• 20. Ground Distribution
• 21. Headlights – Headlamps Circuit
• 22. Headlights – Headlamps Leveling Circuit
• 23. Heated Steering Wheel Circuit
• 24. Instrument Cluster
• 25. Interior Lights – Courtesy Lamps Circuit (W_ Panoramic Sunroof)
• 26. Interior Lights – Courtesy Lamps Circuit (W_O Panoramic Sunroof)
• 27. Interior Lights – Instrument Illumination Circuit
• 28. Memory Systems – Drivers Memory Seat Circuit
• 29. Memory Systems – Memory Mirrors Circuit
• 30. Memory Systems – Memory Power Tilt amp Power Telescopic Circuit
• 31. Mirrors – Electrochromic Mirror Circuit
• 32. Mirrors – Power Mirrors Circuit
• 33. Navigation – Mobile Telematic System Circuit
• 34. Navigation – Navigation Circuit
• 35. Navigation – Parking Assistant Circuit
• 36. Power Distribution
• 37. Power Tops
• 38. Power Windows – Power Windows Circuit
• 39. Power Windows – Rear Curtain Circuit
• 40. Seats – Climate Control Seats Circuit
• 41. Seats – Driver Power Seat Circuit
• 42. Seats – Heated Seats Circuit
• 43. Seats – Passenger Power Seat Circuit (4-Way)
• 44. Seats – Passenger Power Seat Circuit (8-Way)
• 45. Shift Interlock
• 46. Sound Systems – W_ Navigation
• 47. Sound Systems – W_O Navigation W_ Amplifier
• 48. Sound Systems – W_O Navigation W_O Amplifier
• 49. Starting_Charging – Charging Circuit
• 50. Starting_Charging – Starting Circuit (W_ Smart Key)
• 51. Starting_Charging – Starting Circuit (W_O Smart Key)
• 52. Supplemental Restraints
• 53. Transmissions
• 54. Trunk, Tailgate, Fuel Doors – Trunk amp Fuel Door Release Circuit
• 55. Warning Systems – Chime Circuit
• 56. Warning Systems – Tire Pressure Monitoring Circuit
• 57. Wiper_Washer – W_ Rain Sensor
• 58. Wiper_Washer – W_O Rain Sensor
• 59. Brake Control Solenoid Valve (26_B VFS)
• 60. Clutch Control Solenoid Valve (35R_C VFS)
• 61. A_C Control System (Auto) – Schematic Diagrams
• 62. A_C Control System (Manual) – Schematic Diagrams
• 63. A_V amp Navigation – Schematic Diagrams
• 64. Accelerator Position Sensor (APS)
• 65. Air Ventilation Seat
• 66. Anti-lock Brake System (ABS) – Schematic Diagrams
• 67. Anti-lock Brake System (ABS) – Service Tips
• 68. Audio System – Schematic Diagrams
• 69. Auto Headlamp Leveling System (AHLS) – Schematic Diagrams
• 70. Auto Headlamp Leveling System (AHLS) – Service Tips
• 71. Auto Lighting Control System
• 72. Auto Lights – Schematic Diagrams
• 73. Auto Lights – Service Tips
• 74. Automatic Transaxle Control System
• 75. Automatic Transaxle Control System – Schematic Diagrams
• 76. AVN System
• 77. Back-Up Lamps – Schematic Diagrams
• 78. Back-Up Lamps – Service Tips
• 79. Barometric Pressure Sensor (BPS)
• 80. Body Control Module (BCM)
• 81. Button Engine Start System
• 82. Camshaft Position Sensor (CMPS)
• 83. Canister Close Valve (CCV)
• 84. Charging System – Schematic Diagrams
• 85. Charging System – Service Tips
• 86. Climate Seat Control System – Schematic Diagrams
• 87. Clock amp Cigarette Lighter (Power Outlet) System – Schematic Diagrams_001
• 88. Clock amp Cigarette Lighter (Power Outlet) System – Schematic Diagrams_002
• 89. Cooling System – Schematic Diagrams
• 90. Cooling System – Service Tips
• 91. Courtesy amp Trunk Lamps – Schematic Diagrams_001
• 92. Courtesy amp Trunk Lamps – Schematic Diagrams_002
• 93. Crankshaft Position Sensor (CKPS)
• 94. Cruise Control Switch
• 95. Cruise Control System
• 96. Curtain System – Schematic Diagrams
• 97. CVVT Oil Control Valve (OCV)
• 98. CVVT Oil Temperature Sensor (OTS)
• 99. Data Link Details – Schematic Diagrams
• 100. Defogger System – Schematic Diagrams
• 101. Door Control Module System – Schematic Diagrams
• 102. Electro Chromic Mirror System – Schematic Diagrams
• 103. Electronic Stability Control (ESC) System – Schematic Diagrams
• 104. Electronic Stability Control (ESC) System – Service Tips
• 105. Engine Control Module (ECM)
• 106. Engine Control System – Schematic Diagrams
• 107. Engine Control System – Service Tips
• 108. Engine Coolant Temperature Sensor (ECTS)
• 109. ESC (Electronic Stability Control) System
• 110. ETC (Electronic Throttle Control) System
• 111. Fog Lamps – Schematic Diagrams
• 112. Fuel Filler Door amp Trunk Lid Opener – Schematic Diagrams_001
• 113. Fuel Filler Door amp Trunk Lid Opener – Schematic Diagrams_002
• 114. Fuel Filler Door amp Trunk Lid Opener – Service Tips_001
• 115. Fuel Filler Door amp Trunk Lid Opener – Service Tips_002
• 116. Fuel Tank Pressure Sensor (FTPS)
• 117. Fuse amp Relay Information – Schematic Diagrams
• 118. Ground Distribution – Schematic Diagrams
• 119. Hands Free Switch
• 120. Head Lamps – Schematic Diagrams
• 121. Head Lamps – Service Tips
• 122. Heated Oxygen Sensor (HO2S)
• 123. Horn – Schematic Diagrams
• 124. Illuminations – Schematic Diagrams_001
• 125. Illuminations – Schematic Diagrams_002
• 126. Immobilizer Control – Schematic Diagrams
• 127. Immobilizer System
• 128. Immobilizer System – Service Tips
• 129. IMS (Integrated Memory System)
• 130. IMS Power Seat Control
• 131. Indicators amp Gauges – Schematic Diagrams
• 132. Inhibitor Switch
• 133. Injector
• 134. Input Speed Sensor
• 135. Instrument Cluster _ Carrier
• 136. Intake Air Temperature Sensor (IATS)
• 137. Integrated Memory System (IMS) – Schematic Diagrams
• 138. Intelligent Power Switch (IPS) System – Schematic Diagrams
• 139. Keyless Entry amp Burglar Alarm System – Schematic Diagrams_001
• 140. Keyless Entry amp Burglar Alarm System – Schematic Diagrams_002
• 141. Knock Sensor (KS)
• 142. Line Pressure Control Solenoid Valve
• 143. Manifold Absolute Pressure Sensor (MAPS)
• 144. Mobile Telematic System (MTS) – Schematic Diagrams
• 145. Motor Driven Power Steering (MDPS) System – Schematic Diagrams
• 146. Motor Driven Power Steering (MDPS) System – Service Tips
• 147. Multimedia Jack
• 148. Output Speed Sensor
• 149. Overdrive Clutch Control Solenoid Valve (OD_C VFS)
• 150. Panorama roof
• 151. Parking Assist System – Schematic Diagrams
• 152. Parking Assist System – Service Tips
• 153. Passenger Compartment Fuse Details – Schematic Diagrams
• 154. Power Distribution – Schematic Diagrams
• 155. Power Door Locks – Schematic Diagrams
• 156. Power Door Locks – Service Tips
• 157. Power Outside Mirror System – Schematic Diagrams
• 158. Power Seat Control Switch
• 159. Power Seat System Drvier – Schematic Diagrams
• 160. Power Seat System Passenger – Schematic Diagrams
• 161. Power Window Motor
• 162. Power Window Switch
• 163. Power Window System – Schematic Diagrams
• 164. Power Window System – Service Tips
• 165. Purge Control Solenoid Valve (PCSV)
• 166. Rail Pressure Sensor (RPS)
• 167. Rain Sensor
• 168. Schematic Diagrams_001
• 169. Schematic Diagrams_002
• 170. Schematic Diagrams_003
• 171. Schematic Diagrams_004
• 172. Schematic Diagrams_005
• 173. Schematic Diagrams_006
• 174. Schematic Diagrams_007
• 175. Schematic Diagrams_008
• 176. Schematic Diagrams_009
• 177. Schematic Diagrams_010
• 178. Schematic Diagrams_011
• 179. Schematic Diagrams_012
• 180. SD100 – Fuse amp Relay Information Schematic Diagrams
• 181. SD110 – Power Distribution Schematic Diagrams
• 182. SD120 – Passenger Compartment Fuse Details Schematic Diagrams
• 183. SD130 – Ground Distribution Schematic Diagrams
• 184. SD200 – Data Link Details Schematic Diagrams
• 185. SD253 – Cooling System Schematic Diagrams
• 186. SD313 – Engine Control System Schematic Diagrams
• 187. SD360 – Starting System Schematic Diagrams
• 188. SD373 – Charging System Schematic Diagrams
• 189. SD436 – Vehicle Speed System Schematic Diagrams
• 190. SD450 – Automatic Transaxle Control System Schematic Diagrams
• 191. SD452 – Shift Lock System Schematic Diagrams
• 192. SD563 – Motor Driven Power Steering (MDPS) System Schematic Diagrams
• 193. SD564 – Steering Tilt amp Telescopic System Schematic Diagrams
• 194. SD569 – Supplemental Restraint System (SRS) Schematic Diagrams
• 195. SD587 – Anti-lock Brake System (ABS) Schematic Diagrams
• 196. SD588 – Electronic Stability Control (ESC) System Schematic Diagrams
• 197. SD812 – Fuel Filler Door amp Trunk Lid Opener – Schematic Diagrams
• 198. SD813 – Power Door Locks Schematic Diagrams
• 199. SD814 – Keyless Entry amp Burglar Alarm System Schematic Diagrams
• 200. SD816 – Sunroof System Schematic Diagrams
• 201. SD824 – Power Window System Schematic Diagrams
• 202. SD851 – Electro Chromic Mirror System Schematic Diagrams
• 203. SD856 – Curtain System Schematic Diagrams
• 204. SD876 – Power Outside Mirror System Schematic Diagrams
• 205. SD877 – Integrated Memory System (IMS) Schematic Diagrams
• 206. SD879 – Defogger System Schematic Diagrams
• 207. SD879 – Steering Wheel Heating System Schematic Diagrams
• 208. SD880 – Power Seat System Drvier Schematic Diagrams
• 209. SD880 – Power Seat System Passenger Schematic Diagrams
• 210. SD886 – Climate Seat Control System Schematic Diagrams
• 211. SD889 – Seat Warmer System Driver Schematic Diagrams
• 212. SD889 – Seat Warmer System Passenger Schematic Diagrams
• 213. SD921 – Head Lamps Schematic Diagrams
• 214. SD922 – Auto Headlamp Leveling System (AHLS) Schematic Diagrams
• 215. SD924 – Fog Lamps Schematic Diagrams
• 216. SD925 – Turn amp Hazard Lamps Schematic Diagrams
• 217. SD926 – Back-Up Lamps Schematic Diagrams
• 218. SD927 – Stop Lamps Schematic Diagrams
• 219. SD928 – Tail, Parking amp License Lamps Schematic Diagrams
• 220. SD929 – Courtesy amp Trunk Lamps Schematic Diagrams
• 221. SD940 – Indicators amp Gauges Schematic Diagrams
• 222. SD941 – Illuminations Schematic Diagrams
• 223. SD945 – Clock amp Cigarette Lighter (Power Outlet) System Schematic Diagrams
• 224. SD951 – Auto Lights Schematic Diagrams
• 225. SD952 – Door Control Module System Schematic Diagrams
• 226. SD952 – Intelligent Power Switch (IPS) System Schematic Diagrams
• 227. SD954 – Immobilizer Control Schematic Diagrams
• 228. SD954 – Smart Key Module System Schematic Diagrams
• 229. SD955 – Mobile Telematic System (MTS) Schematic Diagrams
• 230. SD956 – Tire Pressure Monitoring System (TPMS) Schematic Diagrams
• 231. SD957 – Parking Assist System – Schematic Diagrams
• 232. SD961 – Audio System Schematic Diagrams
• 233. SD968 – Horn Schematic Diagrams
• 234. SD969 – A_V amp Navigation Schematic Diagrams
• 235. SD971 – A_C Control System (Auto) Schematic Diagrams
• 236. SD971 – A_C Control System (Manual) Schematic Diagrams
• 237. SD981 – Wiper amp Washer System Schematic Diagrams
• 238. Seat Heater
• 239. Seat Temperature Switch
• 240. Seat Warmer System Driver – Schematic Diagrams
• 241. Seat Warmer System Passenger – Schematic Diagrams
• 242. Shift Lock System – Schematic Diagrams
• 243. Smart Cruise Control Switch
• 244. Smart Cruise Control System
• 245. Smart Cruise Control Unit
• 246. Smart Key Module System – Schematic Diagrams
• 247. Smart Key Module System – Service Tips
• 248. Smart Key Unit
• 249. SS-A Solenoid Valve (ON_OFF)
• 250. SS-B Solenoid Valve (ON_OFF)
• 251. Starting System – Schematic Diagrams
• 252. Starting System – Service Tips
• 253. Steering Wheel Heating System – Schematic Diagrams
• 254. Stop Lamps – Schematic Diagrams
• 255. Stop Lamps – Service Tips
• 256. Sunroof System – Schematic Diagrams
• 257. Sunroof System – Service Tips
• 258. Supplemental Restraint System (SRS) – Schematic Diagrams_001
• 259. Supplemental Restraint System (SRS) – Schematic Diagrams_002
• 260. Tail, Parking amp License Lamps – Schematic Diagrams_001
• 261. Tail, Parking amp License Lamps – Schematic Diagrams_002
• 262. Tail, Parking amp License Lamps – Schematic Diagrams_003
• 263. Tire Pressure Monitoring System (TPMS) – Schematic Diagrams
• 264. Torque Converter Control Solenoid Valve (T_CON VFS)
• 265. TPMS Receiver
• 266. Transaxle Control Module (TCM)
• 267. Transaxle Oil Temperature Sensor
• 268. Turn amp Hazard Lamps – Schematic Diagrams_001
• 269. Turn amp Hazard Lamps – Schematic Diagrams_002
• 270. Turn amp Hazard Lamps – Service Tips_001
• 271. Turn amp Hazard Lamps – Service Tips_002
• 272. Underdrive Brake Control Solenoid Valve (UD_B VFS)
• 273. Variable Intake Solenoid (VIS) Valve
• 274. Vehicle Speed System – Schematic Diagrams
• 275. Vehicle Speed System – Service Tips
• 276. Wiper amp Washer System – Schematic Diagrams
• 277. Wiper amp Washer System – Service Tips
