Acura RSX 2004 Electrical Diagrams L4-2.0L

Date: 2004
Type Of Manual: Electrical Diagrams
Engine: L4-2.0L
Number of Pages: 490
Size: 71.1MB
Format: PDF

Category: Acura Wiring Diagrams PDF

Description

Model List:
- RSX

0.1. Air Conditioning Automatic A_C Circuit
0.2. AntiLock Brakes
0.3. AntiTheft Antitheft Circuit
0.4. AntiTheft Immobilizer Circuit
0.5. Body Computer Multiplex Control Circuit
0.6. Computer Data Lines
0.7. Cooling Fans
0.8. Cruise Control
0.9. Defogger Rear Defogger Circuit
0.10. Door Locks
0.11. Engine Controls
0.12. Exterior Lights Backup Lamps Circuit
0.13. Exterior Lights Exterior Lamps amp Trailer Connector Circuit
0.14. Ground Distribution
0.15. Headlights W_ DRL
0.16. Headlights W_O DRL
0.17. Instrument Cluster
0.18. Interior Lights Courtesy Lamps Circuit
0.19. Interior Lights Entry Light Timer Circuit
0.20. Interior Lights Instrument Illumination Circuit
0.21. Mirrors Heated Mirrors Circuit
0.22. Mirrors W_ Defogger
0.23. Mirrors W_O Defogger
0.24. Power Distribution
0.25. Power Tops
0.26. Power Windows
0.27. Seats Heated Seats Circuit
0.28. Shift Interlock
0.29. Sound Systems W_ Bose System
0.30. Sound Systems W_O Bose System
0.31. Starting_Charging Charging Circuit
0.32. Starting_Charging Starting Circuit
0.33. Supplemental Restraints
0.34. Transmissions A_T Circuit
0.35. Warning Systems
0.36. Wiper_Washer Front Wiper_Washer Circuit
0.37. Wiper_Washer Rear Wiper_Washer Circuit
0.38. A_T Gear Position Indicator
0.39. Additional Information
0.40. Air Bag Systems
0.41. Alternator
0.42. Antilock Brakes _ Traction Control Systems
0.43. Automatic Transmission_Transaxle
0.44. Backup Lamp
0.45. Blower Motor
0.46. Brake Lamp
0.47. Brake Warning Indicator
0.48. Cargo Lamp
0.49. Cellular Phone
0.50. Charging System
0.51. Cigarette Lighter
0.52. Circuit 12 Illumination (Negative)
0.53. Circuit 13 Brake Pedal Position
0.54. Circuit 16 Right Turn Signal
0.55. Circuit 17 Left Turn Signal
0.56. Circuit 196 KeyIn Ignition
0.57. Circuit 20 Taillight Relay
0.58. Circuit 200 Trunk Lid Position
0.59. Circuit 201 Passengers Door Switch
0.60. Circuit 202 Drivers Door Switch
0.61. Circuit 207 (Canada) Parking Brake Position
0.62. Circuit 207 (USA) Parking Brake Position
0.63. Circuit 21 Headlight Relay 1,2
0.64. Circuit 331 Ground For Climate Control Sensors
0.65. Circuit 555 Drivers Door Lock Knob Switch
0.66. Circuit 559 Drivers Door Key Cylinder Switch
0.67. Circuit 564 Passengers Door Key Cylinder Switch
0.68. Circuit 565 Passengers Door Key Cylinder Switch
0.69. Circuit 61 Horn Relay Control
0.70. Circuit D04 Power Source For ECM_PCM Control
0.71. Circuit D05 Reference Voltage For ECM_PCM Sensors
0.72. Circuit D45 Reference Voltage For ECM_PCM Sensors
0.73. Circuit D46 Reference Voltage For ECM_PCM Sensors
0.74. Circuit Diagram
0.75. Circuit Diagrams_001
0.76. Circuit Diagrams_002
0.77. Circuit E90 ECT Sensor Signal
0.78. Circuit E93 Vehicle Speed Sensor Signal
0.79. Circuit F12 Fan Controls
0.80. Circuit F20 Sensor Ground For ECM_PCM Sensors
0.81. Circuit F28 Service Check Signal
0.82. Circuit F55 Service Check Signal
0.83. Circuit M06 (A_T) BackUp Lights
0.84. Circuit M06 (M_T) BackUp Lights
0.85. Circuit M22 A_T Neutral Position
0.86. Circuit M34 A_T Reverse Position
0.87. Circuit M35 A_T Park Position
0.88. Circuit M37 A_T Position D
0.89. Circuit Z20 Logic Ground
0.90. Circuit Z27 Ground For ECM_PCM Sensors
0.91. Circuit Z28 Ground For ECM_PCM Sensors
0.92. Compressor HVAC
0.93. Computers and Control Systems
0.94. Condenser Fan
0.95. Console
0.96. Control Assembly, HVAC
0.97. Cooling System
0.98. Courtesy Lamp
0.99. Cruise Control
0.100. Dashboard _ Instrument Panel
0.101. Daytime Running Lamp
0.102. Diagram 100
0.103. Diagram 1010
0.104. Diagram 1011
0.105. Diagram 101a
0.106. Diagram 101b
0.107. Diagram 102
0.108. Diagram 103
0.109. Diagram 104
0.110. Diagram 105
0.111. Diagram 106
0.112. Diagram 107
0.113. Diagram 108a
0.114. Diagram 108b
0.115. Diagram 109a
0.116. Diagram 109b
0.117. Diagram 230
0.118. Diagram 231
0.119. Diagram 232
0.120. Diagram 233
0.121. Diagram 234
0.122. Diagram 235
0.123. Diagram 236
0.124. Diagram 237
0.125. Diagram 238
0.126. Diagram 239
0.127. Diagram Set 10 (Power Distribution)
0.128. Diagram Set 110 (Exterior Lights)
0.129. Diagram Set 114 (Interior Lights)
0.130. Diagram Set 115 (Entry Light Control System)
0.131. Diagram Set 118 (Trailer Lighting Connector)
0.132. Diagram Set 120 (Power Windows)
0.133. Diagram Set 122 (Moonroof)
0.134. Diagram Set 130 (Keyless_Power Door Locks)
0.135. Diagram Set 132 (Immobilizer System)
0.136. Diagram Set 133 (Security Alarm System)
0.137. Diagram Set 138 (Interlock System (A_T))
0.138. Diagram Set 14 (Ground Distribution)
0.139. Diagram Set 141 (Power Mirrors)
0.140. Diagram Set 147 (Seat Heaters)
0.141. Diagram Set 15 (Splice and Junction Connector Details)
0.142. Diagram Set 150 (Audio System)
0.143. Diagram Set 152 (Cellular Phone System)
0.144. Diagram Set 155 (Accessory Power Sockets)
0.145. Diagram Set 20 (Ignition System)
0.146. Diagram Set 21 (Starting System)
0.147. Diagram Set 22 (Charging System)
0.148. Diagram Set 23 (Fuel and Emissions)
0.149. Diagram Set 31 (VTEC_VTC Control System)
0.150. Diagram Set 34 (Cruise Control)
0.151. Diagram Set 38 (Reverse Lockout System)
0.152. Diagram Set 39 (A_T Controls)
0.153. Diagram Set 40 (Horn)
0.154. Diagram Set 44 (ABS (AntiLock Brake System))
0.155. Diagram Set 47 (SRS (Supplemental Restraint System))
0.156. Diagram Set 50 (Multiplex Control System)
0.157. Diagram Set 60 (HVAC)
0.158. Diagram Set 63 (Fans)
0.159. Diagram Set 64 (Rear Window Defogger)
0.160. Diagram Set 73 (Lightson, Keyin, and Seat Belt Reminders, Key Light Timer, and Low Oil Pressure Indicator)
0.161. Diagram Set 80 (Gauges and Indicators)
0.162. Diagram Set 89 (A_T Gear Position Indicator)
0.163. Diagram Set 91 (Front Wiper_Washer)
0.164. Diagram Set 92 (Rear Wiper_Washer)
0.165. Dome Lamp
0.166. ECM_PCM Circuit Diagrams
0.167. ECM_PCM Electrical Connections
0.168. Electrical Diagrams
0.169. Emission Control Systems
0.170. Engine Control Module
0.171. Entry Lights
0.172. Except Type S
0.173. Exterior Lights
0.174. Fog_Driving Lamp
0.175. Front Wiper_Washer
0.176. Fuel Delivery and Air Induction
0.177. Fuel Gauge
0.178. Fuel Pump
0.179. Fuel Tank Unit
0.180. Fuse Block
0.181. Gauges and Indicators
0.182. Gear Lockout
0.183. GroundToComponents Index
0.184. Hazard Warning Lamps
0.185. Headlights (Canada)
0.186. Headlights (USA)
0.187. Heated Glass Element
0.188. Ignition Switch
0.189. Ignition System
0.190. Immobilizer System
0.191. Information Bus
0.192. Instrument Panel and Console Illumination
0.193. Interior Lighting Module
0.194. Keyless_Power Door Lock System Electrical Diagram_001
0.195. Keyless_Power Door Lock System Electrical Diagram_002
0.196. License Plate Lamp
0.197. Lightson, KeyIn, and Seat Belt Reminders, Key Light Timer, and Low Oil Pressure Indicator
0.198. Map Light
0.199. Marker Lamp
0.200. Oil Pressure Warning Lamp_Indicator
0.201. Parking Lamp
0.202. Power Mirror Electrical Diagram
0.203. Radiator Cooling Fan Control Module
0.204. Radiator Cooling Fan Motor
0.205. Radio, Stereo, and Compact Disc
0.206. Radio_Stereo
0.207. Rear Wiper_Washer
0.208. Seat Heater Electrical Diagram
0.209. Security Alarm System
0.210. Shift Interlock, A_T
0.211. Shift Solenoid, M_T
0.212. Spot Lamp
0.213. Tail Lamp
0.214. Trailer Connector
0.215. Trailer Lamps
0.216. Turn Signals
0.217. Vanity Lamp
0.218. Variable Valve Timing Actuator
0.219. Wiring Diagram Index_001
0.220. Wiring Diagram Index_002
0.221. Wiring Diagrams
