Honda Civic Sedan 2021 Electrical Diagrams L4-2.0L (K20C2)

Date: 2021
Type Of Manual: Electrical Diagrams
Engine: L4-2.0L (K20C2)
Number of Pages: 486
Size: 17.0MB
Format: PDF

Category: Honda Wiring Diagrams PDF

Description

Model List:
- Civic Sedan

1. Air Conditioning – Automatic A_C Circuit
2. Anti-Lock Brakes – Hatchback
3. Anti-Lock Brakes – Sedan
4. Anti-Theft – Forced Entry Circuit
5. Anti-Theft – Immobilizer Circuit
6. Body Computer – Hatchback
7. Body Computer – Sedan
8. Computer Data Lines
9. Cooling Fans
10. Cruise Control
11. Defogger – Hatchback
12. Defogger – Sedan
13. Door Locks
14. Electric Parking Brake Circuit (Hatchback)
15. Electric Parking Brake Circuit (Sedan)
16. Electronic Power Steering
17. Electronic Suspension
18. Engine Controls
19. Exterior Lights – Backup Lamps Circuit (CVT)
20. Exterior Lights – Backup Lamps Circuit (M_T)
21. Exterior Lights – Exterior Lamps Circuit (Hatchback)
22. Exterior Lights – Exterior Lamps Circuit (Sedan)
23. Ground Distribution – Hatchback
24. Ground Distribution – Sedan
25. Headlights
26. Instrument Cluster – Hatchback
27. Instrument Cluster – Sedan
28. Interior Lights – Courtesy Lamps Circuit
29. Interior Lights – Entry Light Timer Circuit
30. Interior Lights – Instrument Illumination Circuit (Hatchback)
31. Interior Lights – Instrument Illumination Circuit (Sedan)
32. Mirrors – Automatic Day_Night Mirror Circuit (Hatchback)
33. Mirrors – Automatic Day_Night Mirror Circuit (Sedan)
34. Mirrors – Power Mirrors Circuit (Hatchback)
35. Mirrors – Power Mirrors Circuit (Sedan)
36. Navigation – Lane Watch Camera Circuit
37. Navigation – Multipurpose Camera Circuit (Hatchback)
38. Navigation – Multipurpose Camera Circuit (Sedan)
39. Navigation – Navigation Circuit (Hatchback)
40. Navigation – Navigation Circuit (Sedan)
41. Navigation – Rear Camera Circuit (Hatchback)
42. Navigation – Rear Camera Circuit (Sedan)
43. Power Distribution – Hatchback
44. Power Distribution – Sedan
45. Power Tops
46. Power Windows
47. Seats – Driver Power Seat Circuit
48. Seats – Heated Seats Circuit
49. Seats – Passenger Power Seat Circuit
50. Shift Interlock – Reverse Lockout Circuit (Hatchback)
51. Shift Interlock – Reverse Lockout Circuit (Sedan)
52. Shift Interlock – Shift Interlock Circuit
53. Sound Systems – Hatchback W_ Navigation
54. Sound Systems – Hatchback W_O Navigation W_ Color Audio
55. Sound Systems – Hatchback W_O Navigation W_ Display Audio
56. Sound Systems – Sedan W_ Color Audio
57. Sound Systems – Sedan W_ Display Audio amp Amplifier
58. Sound Systems – Sedan W_ Display Audio W_O Amplifier
59. Starting_Charging – Charging Circuit
60. Starting_Charging – Starting Circuit (Hatchback W_O Keyless Access System)
61. Starting_Charging – Starting Circuit (Sedan W_O Keyless Access System)
62. Starting_Charging – Starting Circuit (W_ Keyless Access System)
63. Supplemental Restraints
64. Transmissions
65. Trunk, Tailgate, Fuel Doors – Trunk Release Circuit (Hatchback)
66. Trunk, Tailgate, Fuel Doors – Trunk Release Circuit (Sedan)
67. Warning Systems – Hatchback
68. Warning Systems – Sedan
69. Wiper_Washer – Front Wiper_Washer Circuit
70. Wiper_Washer – Rear Wiper_Washer Circuit
71. Accessory Power Sockets Circuit Diagram (2_4-door w_ Keyless Access System)
72. Accessory Power Sockets Circuit Diagram (2_4-door w_o Keyless Access System)
73. Adaptive Cruise Control (ACC) Circuit Diagram (2_4-door)
74. Adaptive Damper System Circuit Diagram (Type-R)
75. Audio and Visual System Circuit Diagram (KA_KC models 2_4-door_ w_ Navigation)_001
76. Audio and Visual System Circuit Diagram (KA_KC models 2_4-door_ w_ Navigation)_002
77. Audio and Visual System Circuit Diagram (KA_KC models 2_4-door_ w_o Navigation, Color Audio Type (5-inch Screen))_001
78. Audio and Visual System Circuit Diagram (KA_KC models 2_4-door_ w_o Navigation, Color Audio Type (5-inch Screen))_002
79. Audio and Visual System Circuit Diagram (KA_KC models 2_4-door_w_o Navigation, Display Audio Type (7-inch Screen))_001
80. Audio and Visual System Circuit Diagram (KA_KC models 2_4-door_w_o Navigation, Display Audio Type (7-inch Screen))_002
81. Auto High-Beam (High-Beam Support System) Circuit Diagram (2_4-door)
82. Automatic Dimming Mirrors Circuit Diagram (2_4-door)
83. Charging System Circuit Diagram (Except K20C1 (w_o Keyless Access System))
84. Climate Control System Circuit Diagram (Except K20C1)
85. Collision Mitigation Braking System (CMBS) Circuit Diagram (2_4-door)_001
86. Collision Mitigation Braking System (CMBS) Circuit Diagram (2_4-door)_002
87. Communication Systems Circuit Diagram (K20C1_ With CAN gateway)
88. Communication Systems Circuit Diagram (K20C1_ Without CAN gateway)
89. Communication Systems Circuit Diagram (K20C2_ w_ CAN gateway)
90. Communication Systems Circuit Diagram (K20C2_ w_o CAN gateway)
91. Cooling Fan Controls Circuit Diagram (Except K20C1 (w_o Keyless Access System))
92. Cruise Control Circuit Diagram
93. Cruise Control Circuit Diagram (Type-R_Si)
94. CVT Electronic Control System Circuit Diagram (K20C2 (CVT))
95. Engine Lubrication Circuit Diagram (Except K20C1 (w_o Keyless Access System))
96. Entry Lights Control System Circuit Diagram (2_4-door w_ Keyless Access System)
97. Entry Lights Control System Circuit Diagram (2_4-door w_o Keyless Access System)
98. EPS Circuit Diagram (2_4-door, w_ LKAS)
99. EPS Circuit Diagram (w_o LKAS)
100. Exterior Lights Circuit Diagram (2_4-door w_ Keyless Access System)
101. Exterior Lights Circuit Diagram (2_4-door w_o Keyless Access System)
102. Fuel and Emissions Systems Circuit Diagram (K20C2)
103. Gauges Circuit Diagram (2_4-door w_ Keyless Access System)
104. Gauges Circuit Diagram (2_4-door w_o Keyless Access System)
105. HomeLink Remote Control System Circuit Diagram
106. Horns Circuit Diagram (2_4-door)
107. Ignition Switch Circuit Diagram (2_4-door)_001
108. Ignition Switch Circuit Diagram (2_4-door)_002
109. Immobilizer System Circuit Diagram (2_4-door)
110. Interior Lights Circuit Diagram (2_4-door w_ Keyless Access System)
111. Interior Lights Circuit Diagram (2_4-door w_o Keyless Access System)
112. Keyless Access System Circuit Diagram (2_4-door)
113. Keyless_Power Door Locks_Security System Circuit Diagram (2_4-door w_ Keyless Access System)_001
114. Keyless_Power Door Locks_Security System Circuit Diagram (2_4-door w_ Keyless Access System)_002
115. Keyless_Power Door Locks_Security System Circuit Diagram (2_4-door w_ Keyless Access System)_003
116. Keyless_Power Door Locks_Security System Circuit Diagram (2_4-door w_o Keyless Access System)_001
117. Keyless_Power Door Locks_Security System Circuit Diagram (2_4-door w_o Keyless Access System)_002
118. Keyless_Power Door Locks_Security System Circuit Diagram (2_4-door w_o Keyless Access System)_003
119. Lane Keeping Assist System (LKAS) Circuit Diagram (2_4-door)
120. LaneWatch Circuit Diagram
121. LaneWatch Circuit Diagram (4-door, Japan Production)
122. Moonroof Circuit Diagram (2_4-door)
123. Parking and Back-Up Sensor System Circuit Diagram
124. Power Mirrors Circuit Diagram (2_4-door w_ Keyless Access System)
125. Power Mirrors Circuit Diagram (2_4-door w_o Keyless Access System)
126. Power Seats Circuit Diagram
127. Power Windows Circuit Diagram (2_4-door w_ Keyless Access System)
128. Power Windows Circuit Diagram (2_4-door w_o Keyless Access System)
129. Rear Window Defogger Circuit Diagram (2_4-door w_ Keyless Access System)
130. Rear Window Defogger Circuit Diagram (2_4-door w_o Keyless Access System)
131. Reminder Systems Circuit Diagram (2_4-door w_ Keyless Access System)
132. Reminder Systems Circuit Diagram (2_4-door w_o Keyless Access System)
133. Reverse Lockout System Circuit Diagram (L15B7_L15BA_K20C1_K20C2 (M_T))
134. Road Departure Mitigation Circuit Diagram (2_4-door)
135. Safety Indicator System Circuit Diagram (2_4-door w_ Keyless Access System)
136. Safety Indicator System Circuit Diagram (2_4-door w_o Keyless Access System)
137. Seat Heaters Circuit Diagram (2_4-door w_ Keyless Access System)
138. Seat Heaters Circuit Diagram (2_4-door w_o Keyless Access System)
139. SRS Circuit Diagram (KA_KC models)
140. Starting System Circuit Diagram (Except K20C1 (w_o Keyless Access System))
141. TPMS Circuit Diagram (w_ TPMS Switch)
142. Trunk Lid Circuit Diagram
143. Turn Signal_Hazard Warning Lights Circuit Diagram (2_4-door w_ Keyless Access System)
144. Turn Signal_Hazard Warning Lights Circuit Diagram (2_4-door w_o Keyless Access System)
145. VSA System Circuit Diagram (2_4-door, Except Japan Production (w_ ACC))
146. VSA System Circuit Diagram (2_4-door, Except Japan Production (w_o ACC))
147. Wipers_Washers Circuit Diagram (2_4-door w_ Keyless Access System)
148. Wipers_Washers Circuit Diagram (2_4-door w_o Keyless Access System)
149. Wireless Charger Circuit Diagram (2_4-door)
