Honda CRX DX 1988 Electrical Diagrams L4-1493cc 1.5L SOHC (D15B2) TBI
$70
- Date: 1988
- Type Of Manual: Electrical Diagrams
- Engine: L4-1493cc 1.5L SOHC (D15B2) TBI
- Number of Pages: 71
- Size: 8.5MB
- Format: PDF
Description
-
Model List:
- CRX DX
- 1. Cooling Fans
- 2. Defogger
- 3. Door Locks
- 4. Mirrors
- 5. Power Windows
- 6. Sound Systems
- 7. Starting_Charging – Charging Circuit
- 8. Starting_Charging – Starting Circuit
- 9. Wiper_Washer – Interval Wiper_Washer Circuit
- 10. Wiper_Washer – Rear Wiper_Washer Circuit
- 11. Air Conditioning System
- 12. Audible Warning Device
- 13. Backup Lamp
- 14. Brake Lamp
- 15. Charging System
- 16. Complete Body amp Chassis Wiring Circuit
- 17. Cooling System
- 18. Display Illumination
- 19. Hazard Warning Lamps
- 20. Headlamp
- 21. Heated Glass Element
- 22. Heating System
- 23. Ignition System Diagrams
- 24. Interior Lighting Module
- 25. Oil Pressure Sender
- 26. Oil Pressure Warning Lamp_Indicator
- 27. Part 1 of 4
- 28. Part 2 of 4
- 29. Part 3 of 4
- 30. Part 4 of 4
- 31. PGI-FI Terminal Pin Location amp Schematic
- 32. Radiator Cooling Fan Motor
- 33. Radio_Stereo
- 34. Starting System
- 35. Sunroof _ Moonroof
- 36. Temperature Gauge
- 37. Temperature Sensor (Gauge)
- 38. Turn Signals
- 39. Wiper and Washer Systems
- 40. Wiring Diagrams
