John Deere HD200, HD300 SelectSpray Attachment For ProGator Operator Manual OMUC29300

John Deere HD300 HD200 SelectSpray Attachment for ProGator Operator Manual OMUC29300-2

John Deere HD300 HD200 SelectSpray Attachment for ProGator Operator Manual OMUC29300-3

John Deere HD200, HD300 SelectSpray Attachment For ProGator Operator Manual OMUC29300

Type Of Manual: Operator Manual
Manual ID: OMUC29300
Format: PDF
Size: 5.0MB
Number of Pages: 68

Category: John Deere Operators Manuals PDF Tag: Agricultural

Description

Model List:
- HD200 SelectSpray Attachment For ProGator
- HD300 SelectSpray Attachment For ProGator

1. Introduction
1.1. Thank You for Purchasing a John Deere Product
1.2. Using Your Operators Manual
1.3. Machine Use
1.4. Special Messages
1.5. Service Literature
1.5.1. Order Service Parts Online
2. Contents
3. Product Identification
3.1. Product Compatibility
3.2. Record Identification Numbers
3.3. Sprayer Sub Components
4. Safety Labels NoText
4.1. Safety Label LocationSprayer Tank
4.2. Safety Label LocationSpray Booms (5.5 m (18 ft.)
4.3. Safety Label LocationSpray Booms (4.66.4 m (1521 ft.)
4.4. Understanding the Machine Safety Labels without Text
4.5. Avoid Injury From Drinking Water
4.6. Avoid Injury From Chemical Hazards
4.7. Read Operators Manual
4.8. Avoid Injury From Crushing
4.9. Read Operators Manual, Avoid Moving Parts, Keep Bystanders Away
4.10. Avoid Injury From Moving Boom
4.11. Avoid Injury From Boom Swing Area
4.12. Read Safety in Machine Operators Manual
4.13. Operate Sprayer Safely
4.14. Parking Safely
4.15. Mix and Handle Chemicals Safely
4.16. Read Chemical Container Label
4.17. Handle Chemical Products Safely
4.18. Practice Safe Maintenance
4.19. Wear Appropriate Clothing
4.20. Avoid High Pressure Fluids
4.21. Dispose of Chemicals Properly
4.22. Handling Waste Product and Chemicals
5. Preparing Vehicle
5.1. Preparing the Machine
5.1.1. Machine Requirements
5.1.2. Prepare for Assembly
5.2. Controller Mount Bracket Kit Components
5.3. Tank Components
5.4. Electrical Components
5.5. Pump and Hydraulic Components
5.6. Personal Wash Tank Components
5.7. Install Control Box
5.7.1. Install Brackets
5.7.2. Install Control Box
5.8. Install Cylinder Support Bracket (HD300)
5.9. Install Sprayer
5.10. Install Power Harness
5.11. Install Console Wire Harness
5.12. Install Sprayer Tank Components
5.12.1. Tank Drain Hose
5.12.2. Personal Wash Tank Hose
5.13. Connect Sprayer Main Harness to Control Box
5.14. Connect Rear Wiring Harness
5.15. Install Frame Clamps
5.15.1. Installing Frame Clamps to Sprayer
5.15.2. Securing Sprayer to Frame
6. Component Overview
6.1. Solution Tank
6.1.1. Solution Tank Diagram
6.2. Manifold (Valve Stack)
6.2.1. Manifold Diagram
6.2.2. Centrifugal Pump Diagram
7. Operating Controls
7.1. Digital Manual Control Box
8. Operating
8.1. Spray Tip Operation
8.2. Spray Tip Selection
8.3. Flood Style Spray Tip
8.3.1. Nozzle Dimensions
8.4. Ultra LowDrift Style Spray Tip
8.4.1. Nozzle Dimensions
8.5. Flat Fan Style Spray Tip
8.5.1. Nozzle Dimensions
8.6. Using Digital Manual Control Box
8.7. Operating the Sprayer
8.7.1. Stopping the Sprayer
8.7.2. Pump Use
8.8. Using the Personal Wash Tank
8.9. Filling and Draining Sprayer Tank
8.9.1. Filling the Tank
8.9.2. Draining the Tank
8.10. Using ThreeWay Valve
8.11. Using the Agitator
8.12. Adjusting Throttling Valves
8.13. Using Boom Wings
8.14. Using Boom Wing Extensions (4.6/6.4 m (15/21 ft) Boom Only)
8.15. Adjust Boom Height
8.16. Adjust Boom Wing Level
8.17. Raising and Lowering Sprayer
8.18. Transporting
9. Removing and Storing
9.1. Prepare Machine for Removal
9.2. Disconnect Hydraulic Hoses
9.3. Disconnect Rear Wiring Harness
9.4. Removing Sprayer Without Support Stands
9.5. Removing Sprayer With Optional Support Stands
9.6. Storing Safety
9.7. Winterization and Storage
9.7.1. Sprayer
9.7.2. Foam Marker (If Equipped)
9.7.3. Hose Reel (If Equipped)
9.7.4. Personal Wash Tank
9.8. Removing From Storage
9.8.1. Sprayer
9.8.2. Foam Marker (If equipped)
9.8.3. Personal Wash Tank
9.9. Remove and Store Control Box
10. Installing
10.1. Installing Sprayer on Machine Without Optional Support Stands
10.2. Installing Sprayer on Machine With Optional Support Stands
11. Optional Attachments and Kits
11.1. Using Eductor
11.1.1. Operating and Transport Positions
11.1.2. Startup
11.1.3. Loading Chemicals into Hopper
11.1.4. Loading Chemical with Optional Suction Lance
11.1.5. Shutdown
11.2. Using Foam Marker
11.2.1. Operating Foam Marker
11.2.2. Adjusting Foam Marker
11.2.3. Preparing Foam Marker Solution
11.2.4. Selecting Concentrate
11.2.5. Mixing Solution
11.3. Using Manual and Electric Hose Reels
11.4. Using Rinse Tank
11.4.1. Filling Rinse Tank
11.4.2. Operating
12. Service
12.1. Service Intervals Standard Equipment
12.1.1. Before Each Use
12.1.2. After Each Use
12.1.3. As Needed
12.1.4. Annually
12.2. Service Intervals Optional Equipment
12.2.1. After Each Use
12.2.2. As Needed
12.2.3. Hours
12.2.4. Hours
12.2.5. Annually
12.2.6. Order Service Parts Online
12.3. Cleaning the Sprayer
12.4. Servicing the Inline Strainer
12.5. Verifying Sprayer Output
12.6. Checking Main Circuit Breaker
12.7. Checking Fuses and Boom Wing Actuator Circuit Breaker
12.8. Adjusting Boom Wing Spring Tension
12.9. Lubricating Boom Wing Pivots
12.10. Inspecting and Cleaning Vented Fill Covers
12.10.1. Sprayer Tank Fill Cover
12.10.2. Personal Wash and Foam Marker Tanks
12.11. Servicing Foam Marker Kit
12.11.1. Foam Solution Pump
12.11.2. Foam Solution Strainer
12.11.3. Air Line Check Valve
12.11.4. Foamhead Check Valves
12.11.5. Foamhead Cleaning
12.11.6. Winterization
12.12. Lubricating Ground Wheels
12.13. Lubricating Jack Stands
12.14. Servicing Hose Reel
12.14.1. Lubricating Electric Hose Reel
12.14.2. Lubricating Manual Hose Reel
12.14.3. Adjusting Tension Brake
12.15. Installing a Test Flow Meter
12.16. Installing a Test Pressure Gauge
13. Troubleshooting
13.1. Using Troubleshooting Chart
13.2. SelectSpray HD200 HD300
14. Specifications
14.1. Boom 5.5 m (18 ft.) Spray Width
14.2. Extendable Boom 4.6 / 6.4 m (15 / 21 ft.) Spray Width
14.3. Centrifugal Pump
14.4. Personal Wash Tank
14.5. Optional Equipment
14.5.1. Foam Maker
14.5.2. Ground Plane Wheel
14.5.3. Hose Reel
14.6. Nozzle Flow Rate
14.7. Centrifugal Pump Performance Chart
15. John Deere Quality Statement
15.1. John Deere Quality
