John Deere Waratah HTH624C Harvester Head Operator Manual WA111775
John Deere Waratah HTH624C Harvester Head Operator Manual WA111775 - Image 2
John Deere Waratah HTH624C Harvester Head Operator Manual WA111775 1

John Deere Waratah HTH624C Harvester Head Operator Manual WA111775

$30

  • Type Of Manual: Operator Manual
  • Manual ID: WA111775
  • Format: PDF
  • Size: 9.3MB
  • Number of Pages: 86
Category: Tag:
Description
  • Model List:

    • Waratah HTH624C Harvester Head
  • 1. Contents
  • 1.1. General
  • 1.1.1. Copyright
  • 1.1.2. General Information
  • 1.1.3. Manual Replacement
  • 1.1.4. Warranty
  • 1.1.5. Avoid Unauthorised Machine Modifications
  • 1.1.6. Features
  • 1.2. SafetyOperator Safety Precautions
  • 1.2.1. Only Operate If Qualified
  • 1.2.2. Lock Tilt Bracket
  • 1.2.3. Recommended Harvester Head Position for Top Saw Chain and Top Saw Bar Maintenance
  • 1.2.4. Recommended Harvester Head Position for Main Saw Chain and Main Saw Bar Maintenance
  • 1.3. SafetyGeneral Precautions
  • 1.3.1. Operator Risk
  • 1.3.2. General Safety
  • 1.3.3. Operational Safety
  • 1.3.4. Recognise Safety Information
  • 1.3.5. Wear Protective Equipment
  • 1.3.6. Operating Precautions
  • 1.3.7. Keep Clear of Saw
  • 1.3.8. Avoid Chain Shot
  • 1.3.9. Beware of Chain shot
  • 1.3.10. Chain Shot Guard Inspection
  • 1.3.11. Never Operate Without Reading Manual
  • 1.3.12. Never Stand on the Harvester Head
  • 1.4. SafetyOperation Precautions
  • 1.4.1. Read Manuals Before Operating
  • 1.4.2. Keep Personnel Off the Harvester Head
  • 1.4.3. Pinch Area
  • 1.4.4. Do Not Stare into the Laser Beam
  • 1.4.5. Laser Find End Safety
  • 1.4.6. Waratah Key Switch Control (Threeposition)
  • 1.4.7. Waratah Switch Control (Twoposition)
  • 1.4.8. Lockable battery disconnect switch
  • 1.4.9. To activate manual mode
  • 1.4.10. H16 Controller Power
  • 1.4.11. Avoid Work Site Hazards
  • 1.4.12. Avoid Highpressure Oils
  • 1.4.13. Avoid Highpressure Fluids
  • 1.4.14. Dispose of Waste Properly
  • 1.5. SafetyMaintenance Precautions
  • 1.5.1. Prepare for Service Safety
  • 1.5.2. Servicing and Maintenance Safety
  • 1.5.3. Remove Paint before Welding or Heating
  • 1.5.4. Make Welding Repairs Safely
  • 1.5.5. Service Accumulator Systems Safely
  • 1.6. SafetySafety Signs and Labels
  • 1.6.1. Harvester Head Label Positions
  • 1.6.2. Cab labels (twoposition Waratah switch)
  • 1.7. SafetyGeneral Carrier Precautions
  • 1.7.1. Recommendations For Processing on the Landing
  • 1.7.2. Recommendations for Tree Felling
  • 1.7.3. Use and Maintain a Safetybelt
  • 1.7.4. Do Not Operate Unless Seated
  • 1.7.5. Welding
  • 1.7.6. Carrier Class Head Type
  • 1.7.7. Inspect the Harvester Head
  • 1.7.8. Key Ring Caution and ID
  • 1.7.9. Operator Protective Structures
  • 1.7.10. Driving
  • 1.7.11. Processing
  • 1.7.12. Bucking and Piling
  • 1.8. OperationGeneral Operation
  • 1.8.1. General Operation
  • 1.8.2. Planning Area Preparation
  • 1.9. OperationClear Cut Harvesting
  • 1.9.1. Felling
  • 1.9.2. Felling Process
  • 1.9.3. Delimbing
  • 1.9.4. Fall and Delimb
  • 1.10. OperationThinning Techniques
  • 1.10.1. Plantation Out RowCut To Length at Stump
  • 1.10.2. Plantation Out RowFull Tree Thinning
  • 1.10.3. Select Thinning
  • 1.11. OperationProcessing
  • 1.11.1. General
  • 1.11.2. Debarking
  • 1.11.3. Measuring
  • 1.12. OperationCutting
  • 1.12.1. General
  • 1.12.2. Using The Main Saw Unit
  • 1.12.3. Using The Top Saw Unit
  • 1.13. OperationSpecial Techniques
  • 1.13.1. Use of Double Cuts
  • 1.13.2. Quarter Cutting
  • 1.13.3. Falling MultiLeaders
  • 1.13.4. Falling On Hillside
  • 1.14. OperationMiscellaneous
  • 1.14.1. Unattended Harvester Head
  • 1.14.2. Delimbing MultiLeaders
  • 1.15. MaintenanceFluids and Lubricants
  • 1.15.1. Recommended Hydraulic System Fluid
  • 1.15.2. Chain Oil
  • 1.15.3. Grease Point Location
  • 1.15.4. Grease Point LocationUpper Delimb Knife
  • 1.15.5. Grease Point LocationFeed Unit
  • 1.15.6. Grease Point LocationFeed Arm
  • 1.15.7. Grease Point LocationTilt Bracket
  • 1.15.8. Grease Point LocationLength Measuring Unit
  • 1.15.9. Grease Measuring Wheel Bearings
  • 1.15.10. Grease Point LocationTop Saw Unit
  • 1.15.11. Grease Point LocationMain Saw Unit (SC100 Option)
  • 1.15.12. Grease Point LocationMain Saw Unit (3/4 Saw Option)
  • 1.16. MaintenanceSchedule
  • 1.16.1. Periodic Maintenance Record
  • 1.16.2. MaintenanceEvery 8 Hours or Daily
  • 1.16.3. MaintenanceEvery 50 Hours or Weekly
  • 1.16.4. MaintenanceEvery 200250 Hours or Monthly
  • 1.16.5. MaintenanceEvery 1000 Hours
  • 1.16.6. MaintenanceEvery 2000 Hours or Yearly
  • 1.17. MaintenanceGeneral
  • 1.17.1. Unified Inch Bolt and Cap Screw Torque Values
  • 1.17.2. Metric Bolt and Cap Screw Torque Values
  • 1.17.3. Additional Metric Cap Screw Torque Values
  • 1.18. MaintenanceOperation Checkout
  • 1.18.1. Fault Finding
  • 1.18.2. Operational Checks
  • 1.18.2.1. Super Cut 100Operational Checks
  • 1.18.2.2. Chain Jumps Off Bar
  • 1.18.2.3. Chain Lubrication System Malfunction
  • 1.18.2.4. Oil Leaking From Saw Unit
  • 1.18.2.5. Saw Bar Feed Out Malfunction
  • 1.19. MiscellaneousCarrier
  • 1.19.1. Prevent Fires
  • 1.19.2. In Case of Carrier Fire
  • 1.19.3. Welding on the carrier or harvester head
  • 1.19.4. Welding on Carrier TimberRite
  • 1.19.5. Using booster batteries
  • 1.19.6. Using Booster Batteries TimberRite
  • 1.20. MiscellaneousMeasurements
  • 1.20.1. Metric and Imperial Unit Expressions
  • 1.21. MiscellaneousSpecification Conversion
  • 1.21.1. Pressure
  • 1.21.2. Miscellaneous
  • 1.22. MiscellaneousWood Measurement
  • 1.22.1. Wood Measurement Equivalents
