Manitou MHT 10180 129M ST4 S1, MHT 10230 129M ST4 S1, MHT-X 10180 129M ST3A S1, MHT-X 10230 129M ST3A S1 Repair Manual 648914EN
$30
- Type Of Manual: Repair Manual
- Manual ID: 648914EN
- Format: PDF
- Size: 210.0MB
- Number of Pages: 748
Description
-
Model List:
- MHT 10180 129M ST4 S1
- MHT 10230 129M ST4 S1
- MHT-X 10180 129M ST3A S1
- MHT-X 10230 129M ST3A S1
- 1. Pdg648914EN
- 1.1. Page de garde / Front page
- 2. Som_GeneEN
- 3. Group_00_MR648914EN
- 3.1. Som_GR00_EN
- 3.2. Group_00
- 3.2.1. _00_EN
- 3.2.1.1. PREAMBLE
- 3.2.1.2. MAINTENANCE POSITION
- 3.2.1.3. RULES FOR MAINTENANCE
- 3.2.2. _01_EN
- 3.2.2.1. MLT 960 H140 ST3B / MLTX 960 H140 ST3A
- 3.2.3. _03_EN
- 3.2.3.1. IDENTIFICATION PLATES
- 3.2.3.2. LOCATION
- 3.2.4. _04_EN
- 3.2.4.1. STANDARD TIGHTENING TORQUES
- 3.2.4.2. LUBRICANTS AND FUEL
- 4. Group_10_MR648914EN
- 4.1. Som_GR10_EN
- 4.2. Group_10
- 4.2.1. _01_EN
- 4.2.1.1. MHT1490/10130 ENGINE CHARACTERISTICS
- 4.2.1.2. MHT1490/10130 X ENGINE CHARACTERISTICS
- 4.2.2. _03_EN
- 4.2.2.1. ENGINE SURROUNDINGS
- 4.2.2.2. ENGINE MHT 10180 / 10230 ST4
- 4.2.2.3. ENGINE MHTX 10180 / 10230 ST3A
- 4.2.3. _04_EN
- 4.2.3.1. FAN CONTROL OPERATION
- 4.2.3.2. MHT 10180 / MHT 10230 TIGHTENING TORQUE
- 4.2.3.3. MHTX 10180 / MHTX 10230 TIGHTENING TORQUE
- 4.2.3.4. MHT 10180/10230 ENGINE CONTROL AND ADJUSTMENT
- 4.2.3.5. MHTX 10180 / 10230 ENGINE CONTROL AND ADJUSTMENT
- 4.2.4. _06_EN
- 4.2.4.1. MHT 1490 / MHT 10130
- 4.2.4.2. MHT 1490 / MHT 10130 REMOVING ENGINE AND RADIATOR
- 4.2.4.3. MHTX 1490 / MHTX 10130
- 4.2.4.4. MHTX 1490 / MHTX 10130 REMOVING ENGINE AND RADIATOR
- 4.2.5. _08_EN
- 4.2.5.1. Use of the Onboard Diagnostic Mercedes Engine ST4
- 4.2.5.2. Use of the Onboard Diagnostic Mercedes ST3A
- 4.2.6. _09_EN
- 4.2.6.1. XENTRY DIAGNOSTICS HARDWARE CASE
- 4.2.6.2. MINIDIAG 2 RECOVERY RELEASE 2_5.02.69
- 5. Group_20_MR648914EN
- 5.1. Som_GR20_EN
- 5.2. Group_20
- 5.2.1. _01_EN
- 5.2.1.1. PRINCIPLE OF OPERATION OF GEARBOX
- 5.2.2. _02_EN
- 5.2.2.1. FORWARD GEAR SCHEMATIC DIAGRAM
- 5.2.2.2. REVERSE GEAR SCHEMATIC DIAGRAM
- 5.2.3. _03_EN
- 5.2.3.1. MHT 10120 HYDROSTATIC TRANSMISSION
- 5.2.4. _04_EN
- 5.2.4.1. PRESSURE TAKEOFF POINTS
- 5.2.4.2. PRESSURE TEST PORTS
- 5.2.4.3. PUMP / MOTOR CONTROL AND ADJUSTMENT
- 5.2.4.4. A4VGDA / A6VMDA HYDROSTATIC TRANSMISSION SETTINGS SHEET
- 5.2.4.5. TRANSMISSION ASSEMBLY TIGHTENING TORQUES
- 5.2.5. _06_EN
- 5.2.5.1. REMOVING THE HYDROSTATIC TRANSMISSION
- 5.2.6. _07_EN
- 5.2.7. _09_EN
- 5.2.7.1. BASIS GAUGE KIT
- 6. Group_30_MR648914EN
- 6.1. Som_GR30_EN
- 6.2. Group_30
- 6.2.1. BUMP STOP ADJUSTMENT
- 7. Group_40_MR648914EN
- 7.0.0.1. HYDRAULIC BRAKE ACTUATORS OMCI AXLE (SAHR) SAFETY MEASURES
- 7.0.0.2. DEACTIVATE THE NEGATIVE BRAKE (S.A.H.R SPRING APPLIED HYDRAULIC RELEASE) TYPE 1
- 7.0.0.3. ADJUSTMENT OF THE NEGATIVE BRAKE ACTUATORS (S.A.H.R SPRING APPLIED HYDRAULIC RELEASE) TYPE 1.1
- 7.0.0.4. ADJUSTMENT OF THE NEGATIVE BRAKE ACTUATORS (S.A.H.R SPRING APPLIED HYDRAULIC RELEASE) TYPE 1.2
- 7.0.0.5. MEASUREMENT OF THE WET BRAKES WEAR OMCI AXLE TYPE 1
- 7.0.0.6. MEASUREMENT OF THE WET BRAKES WEAR OMCI AXLE RECORD (Sample only)
- 7.0.0.7. DEACTIVATE THE NEGATIVE BRAKE (S.A.H.R SPRING APPLIED HYDRAULIC RELEASE) TYPE 2
- 7.0.0.8. ADJUSTMENT OF THE NEGATIVE BRAKE ACTUATORS (S.A.H.R SPRING APPLIED HYDRAULIC RELEASE) TYPE 2.1
- 7.0.0.9. ADJUSTMENT OF THE NEGATIVE BRAKE ACTUATORS (S.A.H.R SPRING APPLIED HYDRAULIC RELEASE) TYPE 2.2
- 7.0.0.10. MEASUREMENT OF THE WET BRAKES WEAR OMCI AXLE (TYPE 2 ACTUATOR)
- 7.0.0.11. MEASUREMENT OF THE WET BRAKES WEAR OMCI AXLE RECORD (Sample only)
- 7.0.0.12. TIGHTENING TORQUES
- 7.0.1. _06_EN
- 7.0.1.1. PREPARATION AND SAFETY INSTRUCTIONS
- 7.0.1.2. BRAKE REMOVAL
- 7.0.2. _07_EN
- 7.0.2.1. PREPARATION AND SAFETY INSTRUCTIONS
- 7.0.2.2. BRAKE REFIT
- 7.0.3. _09_EN
- 7.0.3.1. HYDRAULIC BRAKE BLEED KIT
- 8. Group_50_MR648914EN
- 8.0.0.1. INDEX OF COMPONENTS
- 8.0.1. _04_EN
- 8.0.1.1. PREPARATION AND SAFETY INSTRUCTIONS
- 8.0.1.2. ADJUSTING THE SLIDING BLOCKS
- 8.0.1.3. CABLE REEL ADJUSTMENT
- 8.0.2. _06_EN
- 8.0.2.1. GENERAL INFORMATION
- 8.0.3. _07_EN
- 8.0.3.1. GENERAL INFORMATION
- 8.0.3.2. PRELIMINARY OPERATIONS
- 8.0.3.3. PREPARATION AND SAFETY INSTRUCTIONS
- 8.0.3.4. REFITTING THE BOOM ON THE VEHICLE
- 8.0.3.5. REFITTING THE COMPONENTS ON THE BOOM
- 8.0.3.6. REFIT THE EXTENSION CYLINDER
- 8.0.4. _09_EN
- 8.0.4.1. FLARE NUT WRENCH
- 9. Group_70_MR648914EN
- 9.1. Som_GR70_EN
- 9.2. Group_70
- 9.2.1. _01_EN
- 9.2.2. _02_EN
- 9.2.2.1. MOVEMENTS HYDRAULIC SYSTEM LEGEND
- 9.2.3. _03_EN
- 9.2.3.1. KEY POSITION FOR HYDRAULIC COMPONENTS
- 9.2.3.2. SCHEMATIC DIAGRAM 1 HYDRAULIC COMPONENTS POSITION
- 9.2.3.3. SCHEMATIC DIAGRAM 2 HYDRAULIC COMPONENTS POSITION
- 9.2.3.4. SCHEMATIC DIAGRAM 3 HYDRAULIC (Principal circuit)
- 9.2.3.5. SCHEMATIC DIAGRAM 4 HYDRAULIC (Liftingcompensation circuit)
- 9.2.3.6. SCHEMATIC DIAGRAM 5 HYDRAULIC (Jib feed circuit)
- 9.2.3.7. SCHEMATIC DIAGRAM 6 HYDRAULIC (Compensate circuit)
- 9.2.3.8. SCHEMATIC DIAGRAM 7 HYDRAULIC (Lifting circuit)
- 9.2.3.9. SCHEMATIC DIAGRAM 8 HYDRAULIC (Steering circuit)
- 9.2.3.10. SCHEMATIC DIAGRAM 9 HYDRAULIC (Cooling and Leveling circuit)
- 9.2.3.11. SCHEMATIC DIAGRAM 10 HYDRAULIC (Service Brake circuit)
- 9.2.4. _04_EN
- 9.2.4.1. PRESSURE TEST PORT LOCATION
- 9.2.4.2. TIGHTENING TORQUES
- 9.2.5. _06_EN
- 9.2.6. _07_EN
- 9.2.6.1. REASSEMBLING THE SLEWING CYLINDER
- 9.2.7. _09_EN
- 9.2.7.1. PRESSURE GAUGES STANDARD BOX
- 10. Group_80_MR648914EN
- 10.0.0.1. FUSES AND RELAYS
- 10.0.0.2. CONNECTORS
- 10.0.1. _01_B_EN
- 10.0.1.1. ELECTRICAL AND ELECTRONIC SYSTEM OVERVIEW
- 10.0.2. _01_C_EN
- 10.0.2.1. CONTROL UNIT INPUTS/OUTPUT
- 10.0.2.2. TERA 9 INPUTS/OUTPUT
- 10.0.3. _01_D_EN
- 10.0.3.1. A870 24V DC DC CONVERTER
- 10.0.4. _02_EN
- 10.0.4.1. EXAMPLE OF CODES ON ELECTRICAL DIAGRAMS
- 10.0.4.2. CABLE DESIGNATION ON ELECTRICAL WIRING HARNESS
- 10.0.4.3. POSITION OF CONNECTORS BY DIAGRAM
- 10.0.4.4. ELECTRICAL DIAGRAMS BY FUNCTION
- 10.0.5. _03_EN
- 10.0.5.1. KEYS
- 10.0.5.2. LOCATIONS
- 10.0.5.3. LOCATIONS
- 10.0.6. _04_EN
- 10.0.6.1. ELECTRONIC SYSTEM OVERVIEW
- 10.0.7. _08_EN
- 10.0.7.1. DIAGNOSTICS AND TROUBLESHOOTING
- 10.0.7.2. Use of the Onboard Diagnostic trasmission
- 10.0.7.3. troubleshooting
- 10.0.7.4. ANNEX A
- 10.0.8. _09_EN
- 11. Group_85_MR648914EN
- 11.1. Som_Gr85EN
- 11.2. Group_85
- 11.2.1. _03_EN
- 11.2.1.1. HEATING COMPONENTS LOCATION
- 11.2.2. _06_EN
- 11.2.3. _07_EN
- 12. Group_90_MR648914EN
- 12.1. Som_Gr90EN
- 12.2. Group_90
- 12.2.1. REMOVING THE DEF TANK
- 12.2.1.1. REFITTING PROCEDURE
- 13. Group_110_MR648914EN
- 13.1. Som_Gr110EN
- 13.2. Group_110
- 13.2.1. _01_EN
- 13.2.1.1. AIR CONDITIONER
- 13.2.2. _03_EN
- 13.2.2.1. POSITION OF AIR CONDITIONING COMPONENTS
- 13.2.3. _04_EN
- 13.2.3.1. INSTRUCTIONS FOR ASSEMBLING THE AIR CONDITIONER
- 13.2.3.2. FEATURES OF COOLANT R134a
- 13.2.3.3. PRECAUTIONS FOR HANDLING R134a
- 13.2.3.4. FILLING COOLANT IN THE AIR CONDITIONING SYSTEM
- 13.2.3.5. FILLING METHOD
- 13.2.3.6. CHECKING THE WORKING
