Manitou Type 112 Axle Repair Manual 647013EN
$30
- Type Of Manual: Repair Manual
- Manual ID: 647013EN
- Format: PDF
- Size: 93.0MB
- Number of Pages: 208
Description
-
Model List:
- Type 112 Axle
- 1. REPAIR MANUAL 647013EN
- 2. CONTENTS
- 3. INTRODUCTION
- 3.1. VERSION TRACKING
- 4. SPECIFICATIONS
- 4.1. DEFINITION OF VIEWPOINTS
- 4.2. DATA PLATE
- 4.3. CONVERSION TABLES
- 4.3.1. Units of pressure
- 4.3.2. Unit of weight
- 4.3.3. Units of torque
- 4.4. TORQUE SPECIFICATIONS
- 4.4.1. COARSE PITCH
- 4.4.2. FINE PITCH
- 4.5. WHEEL NUT TIGHTENING TORQUES
- 5. MAINTENANCE
- 5.1. MAINTENANCE POINTS
- 5.2. OIL DRAINING MANDATORY PROCEDURE
- 5.2.1. CENTRAL HOUSING
- 5.2.2. PLANETARY GEAR REDUCTION
- 5.3. MAINTENANCE INTERVALS
- 5.4. LUBRICANT SEALANT SPECIFICATIONS
- 6. SAFETY PRECAUTIONS
- 7. CHECKING WEAR AND REPLACING THE BRAKING DISCS
- 8. PLANETARY REDUCTION AND AXLE SHAFT
- 9. DIFFERENTIAL UNIT
- 10. MANUAL EMERGENCY RELEASE
- 10.1. EXPLODED VIEW
- 10.2. RELEASE
- 10.3. ADJUSTMENT
- 11. MECHANICAL PARKING BRAKE
- 11.1. EXPLODED VIEW
- 11.2. DISASSEMBLY
- 11.3. ASSEMBLY
- 12. EXTERNAL HYDRAULIC NEGATIVE BRAKE
- 12.1. EXPLODED VIEW
- 12.2. DISASSEMBLY
- 12.3. ASSEMBLY
- 13. EXTERNAL HYDRAULIC NEGATIVE BRAKE WITH QUICK RELEASE
- 13.1. EXPLODED VIEW
- 13.2. DISASSEMBLY
- 13.3. ASSEMBLY
- 14. INCOMING DRUM BRAKE
- 15. BEVEL PINION SUPPORT
- 16. INCOMING BRAKE (2 AND 3 FUNCTION VERSIONS)
- 17. COMBINED BRAKE
- 18. NORMAL DIFFERENTIAL UNIT
- 19. LIMITED SLIP DIFFERENTIAL UNIT (25 AND 45)
- 20. HYDRAULIC DIFFERENTIAL LOCK
- 21. HYDRAULIC NEGATIVE BRAKE
- 21.1. EXPLODED VIEW
- 21.2. DISASSEMBLY
- 21.3. ASSEMBLY
- 22. PLANETARY REDUCTION 69
- 23. FLANGED PINION TO GEARBOX WITH FLOATING FLANGE
- 24. DIFFERENTIAL WITH BLOCK TO SPHERES 100
- 24.1. EXPLODED VIEW
- 24.2. DISASSEMBLY
- 24.3. ASSEMBLY
- 25. INCORPORATED REDUCTION GEAR AND PINION 602
