Volkswagen Golf SportWagen (BX5) 2016 Electrical Diagrams L4-2.0L DSL Turbo (CRUA)
$70
- Date: 2016
- Type Of Manual: Electrical Diagrams
- Engine: L4-2.0L DSL Turbo (CRUA)
- Number of Pages: 369
- Size: 11.2MB
- Format: PDF
Description
-
Model List:
- Golf SportWagen (BX5)
- 1. Gasoline Engine, CXBA, from December 2014
- 2. V Sockets, from December 2014
- 3. Diesel Engine, CRUA, from December 2014
- 4. A-C System, (KH6), from December 2014
- 5. Access and Start Authorization, (4F2), (4F6), (4L3), from December 2014_001
- 6. Access and Start Authorization, (4F2), (4F6), (4L3), from December 2014_002
- 7. Airbag Systems (USA), (4UM), from December 2014
- 8. Anti-Lock Brake System (ABS), (8T0), (8T2), (8T5), (8T6), (8T7), from December 2014
- 9. Anti-Lock Brake System (ABS), (8T8), from December 2014
- 10. Anti-Theft Alarm System, (7AA), (7AG), (7AI), (7AS), from December 2014
- 11. Automatic Transmission – DSG 0CW, (0EG), from December 2014
- 12. Automatic Transmission – DSG 0D9, (0ES), from December 2014
- 13. Automatic Transmission 6-Speed, (0ER), from December 2014
- 14. Cell Phone System, (9ZX), from December 2014
- 15. Climatronic w- 2-Zone Temperature Control, (9AK), from December 2014
- 16. Convenience System, from December 2014_001
- 17. Convenience System, from December 2014_002
- 18. Convenience System, from December 2014_003
- 19. Convenience System, from December 2014_004
- 20. Convenience System, from December 2014_005
- 21. Convenience System, from December 2014_006
- 22. Converter w- Socket, (9Z2), from December 2014_001
- 23. Converter w- Socket, (9Z2), from December 2014_002
- 24. Driver Assistance Systems Front Camera, (6K3), (QK1), from December 2014
- 25. Dynamic Chassis Control (DCC), (2H4), (2H5), from December 2014
- 26. Emergency Call Module, (EL2), from December 2014
- 27. Fuse Positions, from December 2014_001
- 28. Fuse Positions, from December 2014_002
- 29. Ground Concept, from December 2014
- 30. Headlamps Bixenon HID w- Range Control and Cornering Lamp, (8IM), from December 2014
- 31. Lane change assistance, (7Y8), (7Y9), from December 2014
- 32. Multifunction Steering Wheel, (2FS), (2FW), (2ZH), from December 2014
- 33. Network CAN Bus, from December 2014
- 34. Parking Distance Control w- Parallel Parking Assistance (Park Assist), (7X2), (7X5), from December 2014
- 35. Power Steering, Electromechanical, (1N3), (1N7), from December 2014
- 36. Radiator Fan, from December 2014
- 37. Radio Navigation System, from December 2014_001
- 38. Radio Navigation System, from December 2014_002
- 39. Rearview Camera (Rear Assist), (KA1), from December 2014
- 40. Seat Heating, (4A3), (AV2), from December 2014
- 41. Seats Adjustment, Front Only, (3L9), (3PB), (3PT), from December 2014
- 42. Sound System, (8RU), from December 2014
- 43. Standard Equipment, from December 2014
- 44. Sunroof, (3FU), from December 2014
- 45. Washer System, Headlamps, (8X1), from December 2014
