Volkswagen ID.4 RWD (E21) 2021 Electrical Diagrams ELE-Electric Engine (EBJA)

Date: 2021
Type Of Manual: Electrical Diagrams
Engine: ELE-Electric Engine (EBJA)
Number of Pages: 632
Size: 22.9MB
Format: PDF

Category: Volkswagen Wiring Diagrams PDF

Description

Model List:
- ID.4 RWD (E21)

1. Active Body Work
2. Air Conditioning – Automatic A-C Circuit (1-Zone)
3. Air Conditioning – Automatic A-C Circuit (3-Zone)
4. Anti-Lock Brakes
5. Anti-Theft – Access-Start Circuit
6. Anti-Theft – Forced Entry Circuit
7. Computer Data Lines
8. Cooling Fans
9. Cruise Control
10. Defogger – Rear Defogger Circuit
11. Door Locks
12. Electronic Power Steering
13. Electronic Suspension
14. Engine Controls
15. Exterior Lights – Backup Lamps Circuit
16. Exterior Lights – Exterior Lamps Circuit
17. Exterior Lights – Trailer Tow Circuit
18. Ground Distribution
19. Headlights
20. Heated Steering Wheel Circuit
21. Instrument Cluster
22. Interior Lights – Courtesy Lamps Circuit
23. Interior Lights – Instrument Illumination Circuit
24. Lane Change Assistance Circuit
25. Lane Departure Warning Circuit
26. Memory Systems – Drivers Memory Seat Circuit
27. Memory Systems – Memory Mirrors Circuit
28. Memory Systems – Passengers Memory Seat Circuit
29. Mirrors – Automatic Day-Night Mirror Circuit
30. Mirrors – Heated Mirrors Circuit
31. Mirrors – Power Mirrors Circuit
32. Navigation – Emergency Call Circuit (W- High Variant)
33. Navigation – Emergency Call Circuit (W-O High Variant)
34. Navigation – Navigation Circuit (W- Amplifier)
35. Navigation – Navigation Circuit (W-O Amplifier)
36. Park Brake Release Circuit
37. Parking Assistant Circuit
38. Peripheral Camera Circuit
39. Power Distribution
40. Power Tops
41. Power Windows
42. Rear View Camera Circuit
43. Seats – Driver Power Seat Circuit
44. Seats – Heated Seats Circuit
45. Seats – Passenger Power Seat Circuit
46. Shift Interlock – Shift Interlock Circuit
47. Sound Systems – W- Amplifier
48. Sound Systems – W-O Amplifier
49. Steering Column Circuit
50. Steering Column Electronic Systems Control Module Circuit
51. Supplemental Restraints
52. Transmissions
53. Trunk, Tailgate, Fuel Doors – Trunk amp Fuel Door Release Circuit
54. Vehicle Electrical System Control Module Circuit
55. Warning Systems
56. Wiper-Washer
57. Sockets, from May 2020
58. A-C System, (KC0), from May 2020
59. A-C System, (KH4),(KH7), from May 2020
60. Access and Start Authorization, (4I6), (4I7), (4I8), (4K5), (4K6), (4K7), from May 2020_001
61. Access and Start Authorization, (4I6), (4I7), (4I8), (4K5), (4K6), (4K7), from May 2020_002
62. Adaptive Cruise Control, (8T8), from May 2020
63. Airbag Systems, (4UM), from August 2020
64. Ambient Lighting, (UD1), (UD2), (UD3), (UD6), from May 2020
65. Anti-Theft Alarm System, (7AL), from May 2020
66. Assistance Systems, (7Y1), from May 2020_001
67. Assistance Systems, (7Y1), from May 2020_002
68. Auxiliary Air Heater (PTC), (7E7), from May 2020
69. Brake System, from May 2020
70. Cell Phone System, (9IJ), (9ZV), from May 2020
71. Communication CAN Bus Network Data Bus, from May 2020
72. Communication, (GW2), from May 2020
73. Communication, (NZ2), (NZ4), from May 2020
74. Convenience CAN Bus Network Data Bus, from May 2020
75. Cooling Fan for Control Modules, From May 2020
76. Data Bus on Board Diagnostic Interface and Diagnostic Link Connector (DLC), from May 2020
77. Driver Assistance Systems CAN Bus Network Data Bus, from May 2020
78. Driver Assistance Systems Front Camera, from May 2020
79. Driver Door Control Modules, (L0L), from May 2020
80. Driver Information System CAN Bus Network Data Bus, from May 2020
81. Dynamic Chassis Control (DCC), (2I0), from May 2020
82. Electric Drive System for Rear Axle, EBJA, From May 2020
83. Electric Drive System, Engine-Motor Control Module, EBJA, From May 2020
84. Engine Sound Generator, from May 2020
85. Ethernet Network Data Bus, from May 2020
86. Front Passenger Door Control Modules, (L0L), from May 2020
87. Fuse Assignment, Engine-Motor Compartment, from May 2020
88. Fuse Assignment, Passenger Compartment, from May 2020
89. Ground Concept in Engine-Motor Compartment, from May 2020
90. Ground Concept in Luggage Compartment, from May 2020
91. Ground Concept in Underbody, from May 2020
92. Ground Concept in Vehicle Interior, from May 2020
93. Headlamp, (8IR), (8IV), from May 2020
94. Headlamp, (8IX), from August 2020
95. High-Voltage Battery Charging, (ES6), From August 2020
96. High-Voltage Battery Charging, (ES7), From May 2020
97. High-Voltage Battery System, (J9B), From February 2021
98. High-Voltage Battery System, (J9D), From May 2020
99. High-Voltage Heater (PTC) for High-Voltage Battery System, From May 2020
100. High-Voltage System CAN Bus Network Data Bus, From May 2020
101. High-Voltage System Pilot Line, From May 2020
102. Hood Contact Switch, from May 2020
103. Horn, from May 2020
104. Infotainment CAN Bus Network Data Bus, from May 2020
105. Instrument Cluster, from May 2020
106. Interior Lighting, from May 2020
107. Interior Rearview Mirror, (4L6), from May 2020
108. Lid Release – Rear, from May 2020
109. Light Switch, from May 2020
110. Multifunction Steering Wheel, from May 2020
111. Multimedia System, from May 2020
112. Parking Distance Control, (7X2),(8A2), from May 2020
113. Peripheral Camera, (KA6), from May 2020
114. Power Rear Lid, (5I6), from May 2020
115. Power Steering, Electromechanical, from May 2020
116. Powertrain CAN Bus Network Data Bus, from May 2020
117. Radiator Fan, From May 2020
118. Rear Window Defogger, from May 2020
119. Rearview Camera (Rear Assist), (KA2), from May 2020
120. Roof Shade, (3FG), from May 2020
121. Seat Adjustment, (1R3), (3PR), (8I6), (L0L), from August 2020
122. Seat Adjustment, (3PT), from August 2020
123. Seat Heating, (4A3), from May 2020
124. Sound System, (9VG), (9VH), from April 2021
125. Special Equipment, Rental Vehicle, (2F2),(2F3), from May 2020
126. Steering Column Electronic Systems, from May 2020
127. Suspension CAN Bus Network Data Bus, from May 2020
128. Tail Lamps, (8VG), from May 2020
129. Tail Lamps, (8VP), from May 2020
130. Thermal Management, (9M0), From May 2020
131. Thermal Management, (9M3), From May 2020
132. Trailer Mode, (1D6), (D3), from August 2020
133. Trailer Mode, (1M6), (D1), from May 2020
134. USB Charging Socket, (U9B), (U9C), from May 2020
135. Windshield Defogger, (4GW), from May 2020
136. Windshield Projection Head Up Display, (KS3), from May 2020
137. Wiper and Washer System, Windshield, from May 2020
