Date: 2008
Type Of Manual: Electrical Diagrams
Engine: V6-3.2L (BKH)
Number of Pages: 718
Size: 60.6MB
Format: PDF

Category: Audi Wiring Diagrams PDF

Description

Model List:
- A4 Quattro Cabriolet (8HE)

1. Air Conditioning – Automatic A_C Circuit (Convertible)
2. Air Conditioning – Automatic A_C Circuit (Except Convertible)
3. Anti-Lock Brakes – Convertible
4. Anti-Lock Brakes – Except Convertible
5. Anti-Theft – Convertible
6. Anti-Theft – Except Convertible
7. Body Computer – Comfort System Central Control Module Circuit (Convertible)
8. Body Computer – Comfort System Central Control Module Circuit (Except Convertible)
9. Computer Data Lines – Data Link Connector Circuit
10. Computer Data Lines – High_Low Bus Circuit
11. Convertible Top Circuit
12. Cooling Fans
13. Cruise Control
14. Defogger – Rear Defogger Circuit (Avant)
15. Defogger – Rear Defogger Circuit (Convertible)
16. Defogger – Rear Defogger Circuit (Except Convertible)
17. Door Locks – Convertible
18. Door Locks – Except Convertible, W_ Rear Power Windows
19. Door Locks – Except Convertible, W_O Rear Power Windows
20. Electronic Power Steering
21. Engine Controls
22. Exterior Lights – Back-up Lamps Circuit
23. Exterior Lights – Exterior Lamps Circuit (Avant)
24. Exterior Lights – Exterior Lamps Circuit (Convertible)
25. Exterior Lights – Exterior Lamps Circuit (Sedan)
26. Ground Distribution – Convertible
27. Ground Distribution – Except Convertible
28. Headlights – Headlamps amp Fog Lamps Circuit (W_ Bi-Xenon amp Cornering Headlights Circuit)
29. Headlights – Headlamps amp Fog Lamps Circuit (W_ Bi-Xenon Headlights Circuit)
30. Headlights – Headlamps amp Fog Lamps Circuit (W_ Standard Headlights)
31. Instrument Cluster – Convertible
32. Instrument Cluster – Except Convertible
33. Interior Lights – Courtesy Lamps Circuit (Avant)
34. Interior Lights – Courtesy Lamps Circuit (Convertible)
35. Interior Lights – Courtesy Lamps Circuit (Sedan)
36. Interior Lights – Instrument Illumination Circuit (Convertible)
37. Interior Lights – Instrument Illumination Circuit (Except Convertible)
38. Memory Systems – Convertible
39. Memory Systems – Except Convertible
40. Mirrors – Automatic Day_Night Mirror Circuit (Convertible)
41. Mirrors – Automatic Day_Night Mirror Circuit (Except Convertible)
42. Mirrors – Heated Mirrors Circuit
43. Mirrors – Power Mirrors Circuit (W_ Auto Tilt-Down Mirrors)
44. Mirrors – Power Mirrors Circuit (W_O Auto Tilt-Down Mirrors)
45. Navigation – Navigation Circuit (Convertible W_ Amplifier)
46. Navigation – Navigation Circuit (Convertible W_ Bose)
47. Navigation – Navigation Circuit (Except Convertible W_ Amplifier)
48. Navigation – Navigation Circuit (Except Convertible W_ Bose)
49. Navigation – Parking Assistant Circuit
50. Power Distribution – Convertible
51. Power Distribution – Except Convertible
52. Power Tops – Sunroof Circuit
53. Power Windows – Power Windows Circuit (Convertible)
54. Power Windows – Power Windows Circuit (Except Convertible)
55. Power Windows – Rear Window Sun Shade Circuit
56. Seats – Front Seat Heater Circuit
57. Seats – Lumbar Circuit (Convertible)
58. Seats – Lumbar Circuit (Except Convertible)
59. Seats – Power Seats Circuit (Convertible)
60. Seats – Power Seats Circuit (Except Convertible)
61. Seats – Rear Heated Seats Circuit
62. Shift Interlock – 6 Speed A_T
63. Shift Interlock – W_ CVT
64. Sound Systems – Convertible W_ Amplifier
65. Sound Systems – Convertible W_ Bose
66. Sound Systems – Except Convertible W_ Amplifier
67. Sound Systems – Except Convertible W_ Bose
68. Starting_Charging – Charging Circuit
69. Starting_Charging – Starting Circuit (W_ A_T)
70. Starting_Charging – Starting Circuit (W_ M_T)
71. Steering Column Electronic Systems Control Module Circuit (Convertible)
72. Steering Column Electronic Systems Control Module Circuit (Except Convertible)
73. Supplemental Restraints – Convertible
74. Supplemental Restraints – Except Convertible
75. Transmissions – A_T Circuit (6 Speed A_T)
76. Transmissions – A_T Circuit (W_ CVT)
77. Trunk, Tailgate, Fuel Doors – W_ Convertible
78. Trunk, Tailgate, Fuel Doors – W_O Convertible
79. Vehicle Electrical System Control Module Circuit (Convertible)
80. Vehicle Electrical System Control Module Circuit (Except Convertible)
81. Warning Systems – Brake Wear Sensor Circuit
82. Wiper_Washer – Jet Heater Circuit
83. Wiper_Washer – Wiper_Washer Circuit
