Case VERSUM 100 CVX, 110 CVX, 120 CVX, 130 CVX Tractor Operator Manual 51496433 PDF
$20
- Type Of Manual: Operator Manual
- Manual ID: 51496433
- Format: PDF
- Size: 33.9MB
- Number of Pages: 650
Description
-
Model List:
- VERSUM 100 CVX Tractor
- VERSUM 110 CVX Tractor
- VERSUM 120 CVX Tractor
- VERSUM 130 CVX Tractor
- 1. GENERAL INFORMATION
- 1.1. Note to the owner
- 1.2. Intended use
- 1.3. Metric and imperial units abbreviations
- 1.4. Electromagnetic interference (EMC)
- 1.5. Product identification
- 1.6. Engine identification
- 1.7. Drive line identification
- 1.8. Cab Certification plate
- 1.9. Product identification plate
- 1.10. Noise level information sheet
- 1.11. Programming tractor functions
- 1.12. Operators manual storage
- 1.13. Before operating the tractor
- 1.14. International symbols
- 1.15. Vibration level information sheet
- 1.16. Machine orientation
- 1.17. Selective Catalytic Reduction (SCR) system
- 2. SAFETY INFORMATION
- 2.1. Safety precautions
- 2.2. Safety Decals
- 2.3. Safety rules
- 2.4. Burn prevention
- 2.5. Prevention of fire or explosions
- 2.6. Fire extinguisher
- 2.7. Protection offered by the tractor
- 2.8. Hazardous substances
- 2.9. Ecology and the environment
- 2.10. Towing the tractor for recovery
- 2.11. Emergency exit
- 2.12. Wheel chocks
- 2.13. Intended use statement
- 2.14. Instructors seat
- 2.15. Safety aspects in accordance with Regulation (EU) 1322/2014 Annex XXII and subsequent amendments and modifications
- 3. CONTROLS AND INSTRUMENTS
- 3.1. ACCESS TO OPERATORS PLATFORM
- 3.2. OPERATORS SEAT
- 3.3. INSTRUCTORS SEAT
- 3.4. FORWARD CONTROLS
- 3.5. LEFTHAND SIDE CONTROLS
- 3.6. RIGHTHAND SIDE CONTROLS
- 3.7. REARWARD CONTROLS
- 3.8. OVERHEAD CONTROLS
- 3.9. INSTRUMENT CLUSTER
- 4. OPERATING INSTRUCTIONS
- 4.1. COMMISSIONING THE UNIT
- 4.2. STARTING THE UNIT
- 4.3. STOPPING THE UNIT
- 4.4. MOVING THE UNIT
- 5. TRANSPORT OPERATIONS
- 5.1. PREPARING FOR ROAD TRANSPORT
- 5.2. RECOVERY TRANSPORT
- 6. WORKING OPERATIONS
- 6.1. GENERAL INFORMATION
- 6.2. TRANSMISSION
- 6.3. REAR POWER TAKEOFF
- 6.4. FRONT POWER TAKE OFF
- 6.5. REAR HITCH
- 6.6. FRONT HITCH
- 6.7. HYDRAULIC REMOTE CONTROL VALVES
- 6.8. ELECTROHYDRAULIC REMOTE CONTROL VALVES (where fitted)
- 6.9. HYDRAULIC POWER BEYOND PORT
- 6.10. THREE POINT HITCH
- 6.11. DRAWBARS AND TOWING ATTACHMENTS
- 6.12. TRAILER BRAKING SYSTEMS
- 6.13. WHEEL TRACK ADJUSTMENT
- 6.14. BALLASTING AND TIRES
- 6.15. AUXILIARY POWER CONNECTIONS
- 7. MAINTENANCE
- 7.1. GENERAL INFORMATION
- 7.2. MAINTENANCE CHART
- 7.3. WHEN THE WARNING LIGHT IS ON
- 7.4. EVERY 10 HOURS OR EACH DAY
- 7.5. FIRST 50 HOURS
- 7.6. EVERY 50 HOURS
- 7.7. EVERY 100 HOURS
- 7.8. EVERY 600 HOURS
- 7.9. EVERY 1200 HOURS OR ANNUALLY
- 7.10. EVERY 1200 HOURS OR EVERY 2 YEARS
- 7.11. EVERY 2 YEARS
- 7.12. EVERY 1800 HOURS OR EVERY 2 YEARS
- 7.13. EVERY 2400 HOURS OR EVERY 2 YEARS
- 7.14. EVERY 3600 HOURS OR EVERY 2 YEARS
- 7.15. EVERY 3600 HOURS OR EVERY 4 YEARS
- 7.16. GENERAL MAINTENANCE
- 7.17. STORAGE
- 8. TROUBLESHOOTING
- 8.1. FAULT CODE RESOLUTION
- 8.2. ALARM(S)
- 8.3. SYMPTOM(S)
- 9. SPECIFICATIONS
- 9.1. General dimensions
- 9.2. Minimum turn radius
- 9.3. Axle dimension
- 9.4. Maximum operating angle
- 9.5. Maximum tractor operating weights
- 9.6. Tractor weights
- 9.7. Capacities
- 9.8. Engine
- 9.9. Fuel system
- 9.10. Air cleaner system
- 9.11. Cooling System
- 9.12. Transmission
- 9.13. Rear Power TakeOff (PTO)
- 9.14. Front power takeoff (PTO)
- 9.15. Threepoint hitch
- 9.16. Threepoint hitch front
- 9.17. Hydraulic system
- 9.18. Remote control valves
- 9.19. Front remote control valve couplers
- 9.20. Brakes
- 9.21. Steering
- 9.22. Electrical equipment
- 9.23. Minimum hardware tightening torques
- 10. ACCESSORIES
- 10.1. Radio (where fitted)
- 10.2. External rear view mirrors
- 10.3. Auxiliary head lights and signature lights
- 10.4. Rotating beacon
- 10.5. Frontend loader fixation points
