Volkswagen Amarok DoubleCab (2HB) (MEXICO) 2016 Electrical Diagrams L4-2.0L Turbo (CFPA)

Date: 2016
Type Of Manual: Electrical Diagrams
Engine: L4-2.0L Turbo (CFPA)
Number of Pages: 321
Size: 11.9MB
Format: PDF

Category: Volkswagen Wiring Diagrams PDF

Description

Model List:
- Amarok DoubleCab (2HB) (MEXICO)

1. Petrol Engine, CFPA, from July 2015
2. Speed Automatic Gearbox w- Tiptronic, (G1G), from January 2015
3. Air Supply for Toothed Belt Drive (Engine Dust Kit), (7L3),(7L6),(S1D), from April 2015_001
4. Air Supply for Toothed Belt Drive (Engine Dust Kit), (7L3),(7L6),(S1D), from April 2015_002
5. Airbag Systems for RHD Vehicles, (L0R), from July 2015
6. Airbag Systems, (L0L), from July 2015
7. All-Wheel Drive, from July 2013
8. Anti-Lock Brake System (ABS) w- Electronic Differential Lock (EDL) and Traction Control System (TCS), from July 2013
9. Anti-Theft Alarm System, from July 2014
10. Automatic Anti-Dazzle Interior Mirror, Rain Sensor, from July 2013
11. Auxiliary Coolant Heater, (7VE),(7VL), from January 2015
12. Auxiliary Lights, (2Y1),(E5W), from July 2013
13. Basic Equipment, from July 2015
14. CAN and LIN Bus Networking, Powertrain CAN, Diagnosis CAN, Dash Panel CAN, Convenience CAN, from July 2015
15. Central Locking, Window Regulators and Mirror Adjustment, (L0L), from July 2013_001
16. Central Locking, Window Regulators and Mirror Adjustment, (L0L), from July 2013_002
17. Central Locking, Window Regulators and Mirror Adjustment, (L0L), from July 2013_003
18. Central Locking, Window Regulators and Mirror Adjustment, RHD Vehicles, (L0R), from July 2013_001
19. Central Locking, Window Regulators and Mirror Adjustment, RHD Vehicles, (L0R), from July 2013_002
20. Central Locking, Window Regulators and Mirror Adjustment, RHD Vehicles, (L0R), from July 2013_003
21. Climatic, (9AP), from January 2015
22. Climatronic, (9AD), from January 2015
23. Electronic Logbook, Chip Card Reader Unit, (9ND), from July 2015
24. Exterior Lighting, (8ID-7L3-F0A-F4R),(8ID-7L6), from July 2015
25. Exterior Lighting, (8ID-7L3-F4D-F4H), from July 2015
26. Exterior Lighting, (8IH), from July 2015
27. Fuse Assignment, from July 2015
28. Hardtop, from July 2015_001
29. Hardtop, from July 2015_002
30. Interface for External Use, (UF1), from July 2015
31. Multifunction Steering Wheel, from July 2013
32. Parking Aid (PDC), from July 2015
33. Passenger Compartment Heater and Ventilation System, (9AA), from January 2015
34. Preparation for Mobile Telephone, (9W0),(9ZI),(9ZS), from January 2012
35. Preparation for Mobile Telephone, (9W7),(9ZR), from July 2013
36. Preparation for Radio, (8UB), from July 2013
37. Radio Navigation System, (8AY),(7UC),(7UK),(7T6), from July 2013_001
38. Radio Navigation System, (8AY),(7UC),(7UK),(7T6), from July 2013_002
39. Radio System, (8AE),(8DD),(8UA),(8UE),(I6G),(I6I),(I7A),(I7D), from July 2013
40. Reversing Camera (Rear Assist), from July 2013
41. Seat Heating, from July 2015
42. Supplementary Heater, (9M5), from January 2015
43. Trailer Coupling, (1D1),(1M0), from January 2014
44. Trailer Coupling, (1D7), from January 2014
45. Vehicle Location System, (B1D),(7I1), from July 2012
