Volkswagen Amarok (S7B) (MEXICO) 2022 Electrical Diagrams L4-2.0L DSL Turbo (CSHA)

Date: 2022
Type Of Manual: Electrical Diagrams
Engine: L4-2.0L DSL Turbo (CSHA)
Number of Pages: 405
Size: 14.6MB
Format: PDF

Category: Volkswagen Wiring Diagrams PDF

Description

Model List:
- Amarok (S7B) (MEXICO)

1. Diesel Engine, CNEA,(7L3), from June 2016
2. Speed Automatic Gearbox w- Tiptronic, (G1G),(G1F), from June 2016
3. Adjustable Seat, (3L5), from June 2016
4. Airbag Systems For LHD Vehicles, (L0L),(NZ0),(4X0), from February 2020
5. Airbag Systems For LHD Vehicles, (L0L),(NZ0),(4X3), from February 2020
6. Airbag Systems For RHD Vehicles, (L0R),(4X0), from February 2020
7. Airbag Systems For RHD Vehicles, (L0R),(4X3), from February 2020
8. Airbag Systems, (L0L),(NZ3), from March 2017
9. All-Wheel Drive, from June 2016
10. Anti-Lock Brake System (ABS) w- Electronic Differential Lock (EDL) And Traction Control System (TCS), CFPA, from June 2016
11. Anti-Theft Alarm System, from June 2016
12. Automatic Anti-Dazzle Interior Mirror, Rain Sensor, from June 2016
13. Auxiliary Coolant Heater, (7VE),(7VL), from June 2016
14. Auxiliary Lights, (2Y1),(2Y5),(E5W), from June 2016
15. Basic Equipment, from August 2018
16. Central Locking, Window Regulators And Mirror Adjustment, (L0L), from June 2016_001
17. Central Locking, Window Regulators And Mirror Adjustment, (L0L), from June 2016_002
18. Central Locking, Window Regulators And Mirror Adjustment, (L0L), from June 2016_003
19. Central Locking, Window Regulators And Mirror Adjustment, (L0R), from June 2016_001
20. Central Locking, Window Regulators And Mirror Adjustment, (L0R), from June 2016_002
21. Central Locking, Window Regulators And Mirror Adjustment, (L0R), from June 2016_003
22. Climatic, (9AP), from June 2016
23. Climatronic, (9AD),(KH4), from June 2016
24. Coaxial Cable
25. Data Bus Network, from June 2016
26. Earthing Concept, (L0L), from August 2018
27. Earthing Concept, (L0R), from August 2018
28. Electronic Logbook, Chip Card Reader Unit, (9ND),(9NE), from July 2017
29. Emergency Call Module, (NZ3), from January 2017
30. Exterior Lighting, (8ID), from June 2016
31. Exterior Lighting, (8IH), from June 2016
32. Fuse Assignment, from August 2018
33. Fuse Colours
34. Fuse Colours For ATO Type
35. Fuse Colours For JCase Type
36. Fuse Colours For LP JCase Type
37. Fuse Colours For MAXI Type
38. Fuse Colours For Mini Type
39. Hardtop, (5GF), from August 2018_001
40. Hardtop, (5GF), from August 2018_002
41. Interface For External Use, (IS1), from January 2018
42. Multifunction Steering Wheel, from June 2016
43. Parking Aid (PDC), from January 2018
44. Passenger Compartment Heater And Ventilation System, (9AA), from June 2016
45. Power Assisted Steering, (1N3), from June 2016
46. Preparation For Mobile Telephone, (9IE),(9ZX), from June 2016
47. Preparation For Radio, (8UB), from June 2016
48. Provision For Side Member Lighting, (NU2), from June 2016
49. Radio Navigation System, (8AY), from June 2016_001
50. Radio Navigation System, (8AY), from June 2016_002
51. Radio System, (I7A),(I7C), from June 2016
52. Radio System, (I7D),(I7F), from June 2016
53. Reversing Camera (Rear Assist), from June 2016
54. Seat Heating, (3L3), from June 2016
55. Seat Heating, (3L5), from June 2016
56. Signal Names – DIN Standard 72552
57. Signal Names – Supplement
58. Signal Names, from 2017
59. Supplementary Heater, (9M5), from June 2016
60. Tail Light Clusters, (5HA), from July 2017
61. Trailer Coupling, (1D1), from July 2017
62. Trailer Coupling, (1D7), from June 2016
63. Trailer Coupling, (1M0), from July 2017
64. Tyre Pressure Monitoring System, (7K3), from June 2016
65. Wire Colour
