Volkswagen Passat Sedan (A34) 2021 Electrical Diagrams L4-2.0L Turbo (DTDA)

Date: 2021
Type Of Manual: Electrical Diagrams
Engine: L4-2.0L Turbo (DTDA)
Number of Pages: 1061
Size: 28.3MB
Format: PDF

Category: Volkswagen Wiring Diagrams PDF

Description

Model List:
- Passat Sedan (A34)

1. Air Conditioning – Automatic A-C Circuit (W- Climatronic)
2. Air Conditioning – Automatic A-C Circuit (W-O Climatronic)
3. Anti-Lock Brakes
4. Anti-Theft – Access-Start Circuit
5. Anti-Theft – Forced Entry Circuit
6. Blind Spot Monitoring Circuit
7. Computer Data Lines
8. Cooling Fans
9. Cruise Control
10. Defogger
11. Door Locks
12. Electronic Power Steering
13. Engine Controls
14. Exterior Lights – Backup Lamps Circuit
15. Exterior Lights – Exterior Lamps Circuit
16. Ground Distribution
17. Headlights
18. Instrument Cluster
19. Interior Lights – Courtesy Lamps Circuit
20. Interior Lights – Instrument Illumination Circuit
21. Lane Departure Warning Circuit
22. Memory Systems – Drivers Memory Seat Circuit
23. Memory Systems – Memory Mirrors Circuit
24. Mirrors – Automatic Day-Night Mirror Circuit
25. Mirrors – Power Mirrors Circuit
26. Navigation – Emergency Call Circuit
27. Navigation – Navigation Circuit (W- Amplifier)
28. Navigation – Navigation Circuit (W-O Amplifier)
29. Parking Assistant Circuit (W- Parallel Parking)
30. Parking Assistant Circuit (W-O Parallel Parking)
31. Power Distribution
32. Power Tops
33. Power Windows
34. Rear View Camera Circuit
35. Seats – Driver Power Seat Circuit
36. Seats – Heated Seats Circuit
37. Seats – Passenger Power Seat Circuit
38. Shift Interlock
39. Sound Systems – W- Amplifier
40. Sound Systems – W-O Amplifier
41. Starting-Charging – Charging Circuit
42. Starting-Charging – Starting Circuit
43. Steering Column Electronic Systems Control Module Circuit
44. Supplemental Restraints
45. Tire Pressure Monitoring Circuit
46. Transmissions
47. Trunk, Tailgate, Fuel Doors – Trunk amp Fuel Door Release Circuit
48. Vehicle Electrical System Control Module Circuit
49. Warning Systems – Buzzer Circuit
50. Wiper-Washer
51. Sockets, from January 2019
52. Gasoline Engine, DDSA, from January 2019
53. Access and Start Authorization, (4F6), (4I3), from January 2019_001
54. Access and Start Authorization, (4F6), (4I3), from January 2019_002
55. Access and Start Authorization, (4F6), (7U1), from January 2019_001
56. Access and Start Authorization, (4F6), (7U1), from January 2019_002
57. Adaptive Cruise Control, (6K2), (6K3), from January 2019
58. Airbag Systems, from January 2019
59. Anti-Lock Brake System (ABS) w- ESP, from January 2019
60. Automatic Transmission 6-Speed 09G, (0ER), from January 2019
61. Climatic, (KH6), from January 2019
62. Climatronic, (9AK), from January 2019
63. Convenience System, from January 2019_001
64. Convenience System, from January 2019_002
65. Convenience System, from January 2019_003
66. Convenience System, from January 2019_004
67. Convenience System, from January 2019_005
68. Convenience System, from January 2019_006
69. Convenience System, from January 2019_007
70. Driver Assistance Systems Front Camera, (QK1), from January 2019
71. Emergency Call Module, (EL2), (EL7), from January 2019
72. Fuse Assignment, Engine-Motor Compartment, from January 2019
73. Fuse Assignment, Passenger Compartment, from January 2019
74. Ground Concept, from January 2019
75. Headlamps LED, (8IX), from January 2019
76. Headlamps LED, (8IY), from January 2019
77. Instrument Cluster, from January 2019
78. Lane Change Assistance, (7Y8), (7Y9), from January 2019
79. Multifunction Steering Wheel, from January 2019
80. Network DATA BUS, from January 2019
81. Parking Distance Control, (5I0), (7X5), from January 2019
82. Parking Distance Control, (7X2), from January 2019
83. Parking Distance Control, (7X5), (4E2), from January 2019
84. Power Steering, Electromechanical, from January 2019
85. Radiator Fan, from January 2019
86. Radio Navigation System, from January 2019_001
87. Radio Navigation System, from January 2019_002
88. Rear Lid Closing Aid, (5I0), from January 2019
89. Rearview Camera (Rear Assist), (KA1), from January 2019
90. Seat Adjustment w- Memory Function, (3L4), (8I4), from January 2019
91. Seat Adjustment, (3L5), (3PB), (3PZ), from January 2019
92. Seat Heating, Front, (4A3), from January 2019
93. Seats, Heated Rear, (4A4), from January 2019
94. Sound System, (8RU), from January 2019
95. Standard Equipment, from January 2019_001
96. Standard Equipment, from January 2019_002
97. Standard Equipment, from January 2019_003
98. Standard Equipment, from January 2019_004
99. Standard Equipment, from January 2019_005
100. Standard Equipment, from January 2019_006
101. Standard Equipment, from January 2019_007
102. Standard Equipment, from January 2019_008
103. Standard Equipment, from January 2019_009
104. Standard Equipment, from January 2019_010
105. Standard Equipment, from January 2019_011
106. Standard Equipment, from January 2019_012
107. Standard Equipment, from January 2019_013
108. Standard Equipment, from January 2019_014
109. Standard Equipment, from January 2019_015
110. Standard Equipment, from January 2019_016
111. Standard Equipment, from January 2019_017
112. Standard Equipment, from January 2019_018
113. Standard Equipment, from January 2019_019
114. Standard Equipment, from January 2019_020
115. Standard Equipment, from January 2019_021
116. Standard Equipment, from January 2019_022
117. Standard Equipment, from January 2019_023
118. Standard Equipment, from January 2019_024
119. Standard Equipment, from January 2019_025
120. Standard Equipment, from January 2019_026
121. Standard Equipment, from January 2019_027
122. Standard Equipment, from January 2019_028
123. Standard Equipment, from January 2019_029
124. Standard Equipment, from January 2019_030
125. Sunroof, (3FE), from January 2019
126. Tail Lamps w- LEDs, (8VG), from January 2019
127. Vehicle Electrical System Control Module, from January 2019
