Case Construction King Models 430, 530 Section XII Service Manual 9-70011I PDF
$30
- Type Of Manual: Service Manual
- Manual ID: 9-70011I
- Format: PDF
- Size: 43.2MB
- Number of Pages: 422
Description
-
Model List:
- Construction King Model 430 Section XII
- Construction King Model 530 Section XII
- 1. Section 1020 Detailed Specications 480 and 580 Series B Tractors
- 2. Section F Electrical System
- 3. Section 2013 Cylinder Head and Valves 148, 159, 188 and 201 Spark Ignition Engines
- 4. Section 2014 Cylinder Head and Valves 188 Diesel Engines
- 5. Section 2023 Engines Block Assemblies 201G, 188G, 159G, 148G Spark Ignition Engines
- 6. Section 2024 Engines Block Assembly 188D Diesel Engine
- 7. Section I Servicing The Cav Fuel Injectors
- 8. Section 3022 Roosa Master Model DB Fuel Injection Pumps 188 Series Diesel Engines
- 9. Section 3033 Model 267 Series Zenith Carburetor for the 188G and 159G Spark Igition Engines
- 10. Section 4019 BreakAway Couplings and Portable Hydraulic Cylinders
- 11. Section D Servicing The Remote Hydraulic Valves
- 12. Section O Servicing The Hydrostatic Steering System, Engine Power Pump, Control Valve, Manual Pump, Cylinders
- 13. Section R Servicing The DraftOMatic Hydraulic System, Valve, Rockshaft Assembly
- 14. Section 3SO Servicing The Constant Running Power TakeOff
- 15. Section 65 Four Speed Transmission and Final Drive
- 16. Section 66 Mechanical Shuttle
- 17. Section 67 Dual Range Assembly
- 18. Section 68 11 Inch Traction Clutch
- 19. Section 74 Differential Brakes, Differential Lock and Parking Brake
- 20. Section X Servicing The CaseOMatic 11Inch Torque Converter/ Control Valve/ Pressure Regulator and Pump
