Case Magnum 235, 260, 290, 315, 340, 370 Continuously Variable Transmission (CVT) Tractor Service Manual 47533562 PDF
$30
- Type Of Manual: Service Manual
- Manual ID: 47533562
- Format: PDF
- Size: 337.2MB
- Number of Pages: 4436
Description
-
Model List:
- Magnum 235 Continuously Variable Transmission (CVT) Tractor
- Magnum 260 Continuously Variable Transmission (CVT) Tractor
- Magnum 290 Continuously Variable Transmission (CVT) Tractor
- Magnum 315 Continuously Variable Transmission (CVT) Tractor
- Magnum 340 Continuously Variable Transmission (CVT) Tractor
- Magnum 370 Continuously Variable Transmission (CVT) Tractor
- 1. Contents
- 2. INTRODUCTION
- 3. Engine 10
- 4. Power coupling 19
- 5. Transmission 21
- 6. FourWheel Drive (4WD) system 23
- 7. Front axle system 25
- 8. Rear axle system 27
- 9. Power TakeOff (PTO) 31
- 10. Brakes and controls 33
- 11. Hydraulic systems 35
- 12. Pneumatic system 36
- 13. Hitches, drawbars, and implement couplings 37
- 14. Steering 41
- 15. Cab climate control 50
- 16. Electrical systems 55
- 17. Platform, cab, bodywork, and decals 90
- 18. Electrical Schematic 47451825
- 19. Hydraulic Schematic 47451827
- 20. Hydraulic Schematic 47605412
