Case Maxxum 115-150, 115-150 Multicontroller, CVT 115 Service Manual 47951313 PDF
$30
- Type Of Manual: Service Manual
- Manual ID: 47951313
- Format: PDF
- Size: 14.2MB
- Number of Pages: 399
Description
-
Model List:
- Maxxum 115 Tier 4B (Final) Tractor
- Maxxum 115 Multicontroller Tier 4B (Final) Tractor
- Maxxum CVT 115 Tier 4B (Final) Tractor
- Maxxum 125 Tier 4B (Final) Tractor
- Maxxum 125 Multicontroller Tier 4B (Final) Tractor
- Maxxum CVT 125 Tier 4B (Final) Tractor
- Maxxum 135 Tier 4B (Final) Tractor
- Maxxum 135 Multicontroller Tier 4B (Final) Tractor
- Maxxum CVT 135 Tier 4B (Final) Tractor
- Maxxum 145 Tier 4B (Final) Tractor
- Maxxum 145 Multicontroller Tier 4B (Final) Tractor
- Maxxum CVT 145 Tier 4B (Final) Tractor
- Maxxum 150 Tier 4B (Final) Tractor
- Maxxum 150 Multicontroller Tier 4B (Final) Tractor
- 1. Rear axle system 27
- 1.1. Powered rear axle 100
- 1.2. Rear bevel gear set and differential 106
- 1.3. Planetary and final drives 120
- 2. Power TakeOff (PTO) 31
- 2.1. Rear electrohydraulic control 104
- 2.2. Twospeed rear Power TakeOff (PTO) 114
- 2.3. Threespeed rear Power TakeOff (PTO) 116
- 2.4. Front Power TakeOff (PTO) control 142
- 2.5. Front Power TakeOff (PTO) 146
- 3. Brakes and controls 33
- 3.1. Hydraulic service brakes 202
- 3.2. Parking brake or parking lock 110
- 3.3. Trailer brake hydraulic control 220
- 3.4. Trailer brake pneumatic control 224
- 3.5. Front axle brake 204
