Case Maxxum 115-150, 115-150 Multicontroller, CVT 115 Service Manual 47951321 PDF
$30
- Type Of Manual: Service Manual
- Manual ID: 47951321
- Format: PDF
- Size: 9.6MB
- Number of Pages: 329
Description
-
Model List:
- Maxxum 115 Tier 4B (Final) Tractor
- Maxxum 115 Multicontroller Tier 4B (Final) Tractor
- Maxxum CVT 115 Tier 4B (Final) Tractor
- Maxxum 125 Tier 4B (Final) Tractor
- Maxxum 125 Multicontroller Tier 4B (Final) Tractor
- Maxxum CVT 125 Tier 4B (Final) Tractor
- Maxxum 135 Tier 4B (Final) Tractor
- Maxxum 135 Multicontroller Tier 4B (Final) Tractor
- Maxxum CVT 135 Tier 4B (Final) Tractor
- Maxxum 145 Tier 4B (Final) Tractor
- Maxxum 145 Multicontroller Tier 4B (Final) Tractor
- Maxxum CVT 145 Tier 4B (Final) Tractor
- Maxxum 150 Tier 4B (Final) Tractor
- Maxxum 150 Multicontroller Tier 4B (Final) Tractor
- 1. Electrical systems 55
- 1.1. Transmission control system 024
- 1.2. Transmission speed sensors 020
- 1.3. Transmission pressure sensors 021
- 1.4. Transmission temperature sensors 022
- 1.5. Transmission position sensors 023
- 1.6. Rear Power TakeOff (PTO) control system 048
- 1.7. Parking brake electrical system 031
- 1.8. Cab controls 512
- 1.9. Remote control valve electric control 035
- 1.10. Cab Heating, Ventilation, and AirConditioning (HVAC) controls 051
- 1.11. Heating, Ventilation, and AirConditioning (HVAC) control system 050
- 1.12. Steering control system 047
- 1.13. Rear threepoint hitch electronic control system 130
- 1.14. Global Positioning System (GPS) 911
- 1.15. External lighting switches and relays 405
- 1.16. Cab or platform harnesses and connectors 510
- 1.17. Warning indicators, alarms, and instruments 408
