John Deere 47-Inch Snowblower Operator Manual OMLVU24140
$30
- Type Of Manual: Operator Manual
- Manual ID: OMLVU24140
- Format: PDF
- Size: 1.0MB
- Number of Pages: 20
Description
-
Model List:
- 47-Inch Snowblower
- 1. Introduction
- 1.1. Using Your Operators Manual
- 2. Product Identification
- 2.1. Product Compatibility
- 2.2. Record Purchase Information
- 3. Safety Labels
- 3.1. Safety Label Location
- 3.2. Understanding The Machine Safety Labels
- 3.3. DANGER M144853
- 3.4. WARNING M144854
- 3.4.1. TO AVOID INJURY FROM THROWN OBJECTS
- 3.4.2. CAUTION
- 3.5. DANGER M146743
- 3.5.1. ROTATING SHAFT
- 3.6. DANGER M154693
- 3.6.1. ROTATING BLADE
- 3.7. Certification
- 3.8. Read Safety in Machine Operators Manual
- 3.9. Safe Operation Practices for Ride On Snow Throwers
- 3.10. Training
- 3.11. Preparation
- 3.12. Operation
- 3.13. Parking Safely
- 3.14. Clearing a Clogged Discharge Chute
- 3.15. Maintenance and Storage
- 3.16. Practice Safe Maintenance
- 3.17. Avoid Injury from Moving Parts
- 3.18. Avoid Injury from Hitting Obstructions
- 3.19. Stay Clear of Rotating Drivelines
- 3.20. Avoid High Pressure Fluids
- 4. Assembly
- 4.0.1. Snowblower
- 4.0.2. Drive Assembly (Models 4100, 4010, 4110, 4115, 2320, 2520)
- 4.0.3. Drive Assembly (Models 2210, 2305, 1023E, 1026R)
- 4.1. Install End Plates
- 4.2. Install Discharge Chute and Cables
- 4.3. Install Driveshaft
- 4.4. Lubricate Auger Shaft
- 4.5. Install PTO Shield
- 4.6. Install Tie Strap
- 4.7. Install Hose Fittings (2210, 2305, 2320, 2520, 1023E, 1026R)
- 4.8. Install Hose Fittings (4100, 4010, 4110, 4115)
- 4.9. Install Driveshaft Support Rod
- 4.10. Install Drift Blades
- 5. Installing
- 5.1. Preparing Tractor
- 5.1.1. Required Equipment
- 5.2. Installing Ballast
- 5.2.1. Required ballast
- 5.2.2. To improve traction
- 5.3. Installing Snowblower on Front Hitch
- 5.4. Connecting Driveshaft to Tractor
- 5.5. Connecting Hydraulic Hoses
- 5.6. Checking Discharge Chute Rotation
- 6. Removing and Storing
- 6.1. Removing Ballast
- 6.2. Disconnecting Hydraulic Hoses
- 6.3. Disconnecting Driveshaft From Tractor
- 6.4. Removing Snowblower From Front Hitch
- 6.5. Storing Safety
- 6.6. Storing Attachment
- 7. Operating
- 7.1. Raising and Lowering Snowblower
- 7.2. Operating Snowblower
- 7.2.1. Engaging Snowblower
- 7.2.2. Disengaging Snowblower
- 7.3. Turning Discharge Chute
- 7.4. Adjusting Spout
- 7.5. Adjusting Skid Shoes
- 7.5.1. For smooth surface work
- 7.5.2. For gravel or rough surface work
- 8. Service
- 8.1. Service Intervals
- 8.1.1. Before Each Use
- 8.1.2. Beginning of Season
- 8.1.3. Every 25 Hours
- 8.1.4. The following greases are preferred
- 8.2. Gear Oil
- 8.3. Checking Auger Gearbox Oil Level
- 8.4. Lubricating
- 8.4.1. Auger Shaft
- 8.4.2. Driveshaft
- 8.4.3. Discharge Chute and Cable Pulleys
- 8.4.4. Drive Chain
- 8.5. Adjusting Drive Chain
- 8.6. Replacing Shear Bolt
- 8.7. Servicing Scraper Blade
- 8.8. Replacing Discharge Chute Cables
- 8.8.1. Replacing Right Cable
- 8.8.2. Replacing Left Cable
- 9. Specifications
- 9.1. Inch Snowblower
- 10. Getting Quality Service
- 10.1. Service Literature
- 10.1.1. Order Service Parts Online
- 10.2. Replacement Parts
- 10.3. John Deere Quality Continues with Quality Service
- 11. Table of Contents
