Mazda Truck CX-30 AWD (CANADA) 2022 Electrical Diagrams L4-2.0L (SKYACTIV-G)

Date: 2022
Type Of Manual: Electrical Diagrams
Engine: L4-2.0L (SKYACTIV-G)
Number of Pages: 831
Size: 94.8MB
Format: PDF

Category: Mazda Truck Wiring Diagrams PDF

Description

Model List:
- CX-30 AWD (CANADA)

1. A_C Compressor Control (0740-2) – Wiring Diagrams_Connector Views_Locations
2. Accessory Socket (0921-1) – Wiring Diagrams_Connector Views_Locations
3. Active Driving Display (0922-4) – Wiring Diagrams_Connector Views_Locations
4. AFS (Adaptive Front Lighting System)_Headlight Auto Leveling System (0918-2) – Wiring Diagrams_Connector Views_Locations
5. Air Bag System (Includes Pre-Tensioner Seat Belt Information) (0810-1) – Wiring Diagrams_Connector Views_Locations
6. Audio System (Bose (R) Type Audio) (0920-1) – Wiring Diagrams_Connector Views_Locations
7. Audio System (w_o Bose (R) Type Audio) (0920-2) – Wiring Diagrams_Connector Views_Locations
8. Auto Dimming Mirror (0912-6) – Wiring Diagrams_Connector Views_Locations
9. Automatic Transaxle Control System (0517-1) – Wiring Diagrams_Connector Views_Locations
10. Back-up Light (0918-5) – Wiring Diagrams_Connector Views_Locations
11. Blind Spot Monitoring (BSM) System (1501-3) – Wiring Diagrams_Connector Views_Locations
12. Body Control System (BCM, Electrical Supply Unit (ESU)) (0940-1) – Wiring Diagrams_Connector Views_Locations
13. Brake Light_High-Mount Brake Light (0918-6) – Wiring Diagrams_Connector Views_Locations
14. Charging System (w_o Mazda M Hybrid (SKYACTIV-G 2.0, 2.5)) (0117-1) – Wiring Diagrams_Connector Views_Locations
15. Control System (SKYACTIV-G 2.0, 2.5) (0140-1) – Wiring Diagrams_Connector Views_Locations
16. Cooling System (SKYACTIV-G 2.0, 2.5) (0112-1) – Wiring Diagrams_Connector Views_Locations
17. Cruise Control System (w_o Mazda Radar Cruise Control (MRCC) System (SKYACTIV-G 2.0, 2.5)) (0120-1) – Wiring Diagrams_Connector Views_Locations
18. Data Link Connector (00D-1)
19. Door Lock System (0914-1) – Wiring Diagrams_Connector Views_Locations
20. Driver Monitoring (DM) (1501-5) – Wiring Diagrams_Connector Views_Locations
21. Driver-Side Power Seat (0913-3) – Wiring Diagrams_Connector Views_Locations
22. Dynamic Stability Control (w_ Mazda M Hybrid) (0415-2) – Wiring Diagrams_Connector Views_Locations
23. Dynamic Stability Control (w_o Mazda M Hybrid) (0415-1) – Wiring Diagrams_Connector Views_Locations
24. Electric Parking Brake (w_ Mazda M Hybrid) (0412-2) – Wiring Diagrams_Connector Views_Locations
25. Electric Parking Brake (w_o Mazda M Hybrid) (0412-1) – Wiring Diagrams_Connector Views_Locations
26. Electric Power Steering (EPS) (0613-1) – Wiring Diagrams_Connector Views_Locations
27. Electrical Wiring Schematic (00E-1) – Wiring Diagrams_Connector Views_Locations_001
28. Electrical Wiring Schematic (00E-1) – Wiring Diagrams_Connector Views_Locations_002
29. Forward Sensing Camera (FSC) (1501-2) – Wiring Diagrams_Connector Views_Locations
30. Front Radar Sensor (1501-1) – Wiring Diagrams_Connector Views_Locations_001
31. Front Radar Sensor (1501-1) – Wiring Diagrams_Connector Views_Locations_002
32. Fuel System (SKYACTIV-G 2.0, 2.5) (0114-1) – Wiring Diagrams_Connector Views_Locations_001
33. Fuel System (SKYACTIV-G 2.0, 2.5) (0114-1) – Wiring Diagrams_Connector Views_Locations_002
34. Headlight (0918-1) – Wiring Diagrams_Connector Views_Locations
35. Headlight Manual Leveling System (0918-11) – Wiring Diagrams_Connector Views_Locations
36. Heated Steering Wheel System (0616-1) – Wiring Diagrams_Connector Views_Locations
37. Heater and Air Conditioner System (0740-1) – Wiring Diagrams_Connector Views_Locations
38. Horn (0922-2) – Wiring Diagrams_Connector Views_Locations
39. I-Activ AWD (0318-1) – Wiring Diagrams_Connector Views_Locations
40. Illumination Light (0918-7) – Wiring Diagrams_Connector Views_Locations
41. Indicator Unit (0922-3) – Wiring Diagrams_Connector Views_Locations
42. Instrument Cluster (0922-1) – Wiring Diagrams_Connector Views_Locations
43. License Plate Light_Parking Light_Side Marker Light_Taillight (0918-3) – Wiring Diagrams_Connector Views_Locations
44. Mazda M Hybrid (Includes Charging System Information) (1442-1) – Wiring Diagrams_Connector Views_Locations_001
45. Mazda M Hybrid (Includes Charging System Information) (1442-1) – Wiring Diagrams_Connector Views_Locations_002
46. Mazda Radar Cruise Control (Mrcc) System (1501-7) – Wiring Diagrams_Connector Views_Locations
47. Parking Assist System_360º View Monitor System (1501-4) – Wiring Diagrams_Connector Views_Locations
48. Parking Sensor System (0922-5) – Wiring Diagrams_Connector Views_Locations
49. Power Liftgate (PLG) System (0914-5) – Wiring Diagrams_Connector Views_Locations
50. Power Outer Mirror (0912-4) – Wiring Diagrams_Connector Views_Locations
51. Power Window System (0912-2) – Wiring Diagrams_Connector Views_Locations
52. Rear Seat Belt Reminder System (0810-3) – Wiring Diagrams_Connector Views_Locations
53. Rear Window Defogger (Includes Heated Outer Mirror Information) (0912-1) – Wiring Diagrams_Connector Views_Locations_001
54. Rear Window Defogger (Includes Heated Outer Mirror Information) (0912-1) – Wiring Diagrams_Connector Views_Locations_002
55. Seat Warmer (w_ Driver-Side Power Seat) (0913-2) – Wiring Diagrams_Connector Views_Locations
56. Seat Warmer (w_o Driver-Side Power Seat) (0913-1) – Wiring Diagrams_Connector Views_Locations
57. Shift-Lock System (0518-1) – Wiring Diagrams_Connector Views_Locations_001
58. Shift-Lock System (0518-1) – Wiring Diagrams_Connector Views_Locations_002
59. Starting System (SKYACTIV-G 2.0, 2.5) (0119-1) – Wiring Diagrams_Connector Views_Locations
60. Steering Angle Sensor (0918-8) – Wiring Diagrams_Connector Views_Locations
61. Sunroof (0915-1) – Wiring Diagrams_Connector Views_Locations
62. Telematics Communication System (0922-6) – Wiring Diagrams_Connector Views_Locations
63. Theft-Deterrent System-Mexico Spec. (0914-4) – Wiring Diagrams_Connector Views_Locations
64. Turn and Hazard Warning Light (0918-4) – Wiring Diagrams_Connector Views_Locations
65. Windshield Wiper DE-Icer System (0912-8) – Wiring Diagrams_Connector Views_Locations
66. Wiper and Washer System (0919-1) – Wiring Diagrams_Connector Views_Locations
