Case CX210B MH, CX210B SL Crawler Excavator Service Manual 84275412B PDF
$30
- Type Of Manual: Service Manual
- Manual ID: 84275412B
- Format: PDF
- Size: 10.7MB
- Number of Pages: 108
Description
-
Model List:
- CX210B MH Crawler Excavator
- CX210B SL Crawler Excavator
- 1. SMCX210BMHTOC1EN
- 2. SMCX210BMHTOC0ENSec1900
- 3. _MainBody
- 4. _Deta
- 5. SMCX210BMHTOC1ENSec4900
- 6. _Electrical
- 7. _Interference_Prevention_Device
- 7.1. Functions
- 7.1.1. System Function
- 7.1.2. Interference Prevention System Operation
- 7.1.3. Temporary Cancellation Function
- 7.1.4. Handling Abnormalities
- 7.2. Circuit Explanations
- 7.2.1. Boom (up) Interference Prevention Function
- 7.2.2. Elevator Cab Interference Prevention Function
- 7.2.3. Arm (in) Interference Prevention Function
- 7.2.4. Temporary Cancellation Function
- 7.2.5. Handling Abnormalities (shutoff function)
- 7.2.6. Handling Abnormalities (redundancy function)
- 7.3. Settings Method
- 7.3.1. Start
- 7.3.2. Liftcrane mode
- 7.3.3. Display switching
- 7.3.4. Check
- 7.3.5. Abnormality display
- 7.3.6. Operation Confirmation for Cab Interference Prevention Function
- 7.3.7. Operation Confirmation of Emergency Cancellation
- 7.4. Error Code
- 7.4.1. When an abnormality occurs in the liftcrane device, the warning buzzer sounds in order to perform notification of the abnormality.
- 7.4.2. See below for information on buzzer patterns.
- 7.4.3. Buzzer pattern during abnormality occurrence
