Case Steiger 400, 450, 500, 550, 600, Quadtrac 450, 500, 550, 600 Tier 2 Tractor Operator Manual 51461879 PDF
$20
- Type Of Manual: Operator Manual
- Manual ID: 51461879
- Format: PDF
- Size: 67.3MB
- Number of Pages: 522
Description
-
Model List:
- Steiger 400 Tier 2 Tractor
- Steiger 450 Tier 2 Tractor
- Steiger 500 Tier 2 Tractor
- Steiger 550 Tier 2 Tractor
- Steiger 600 Tier 2 Tractor
- Quadtrac 450 Tier 2 Tractor
- Quadtrac 500 Tier 2 Tractor
- Quadtrac 550 Tier 2 Tractor
- Quadtrac 600 Tier 2 Tractor
- 1. GENERAL INFORMATION
- 1.1. Note to the owner
- 1.2. Intended use
- 1.3. CNH Industrial America LLC technical manuals
- 1.4. Your tractor
- 1.5. ElectroMagnetic Compatibility (EMC)
- 1.6. Product identification
- 1.7. Operators manual storage on the machine
- 1.8. Machine orientation
- 1.9. Component location
- 2. SAFETY INFORMATION
- 2.1. Safety alert symbol and signal word definition
- 2.2. Safety rules
- 2.3. Ecology and the environment
- 2.4. Protective structures
- 2.5. Hazardous substances
- 2.6. Emergency exit
- 2.7. Articulation cylinder locking blocks
- 2.8. Safety signs
- 3. CONTROLS AND INSTRUMENTS
- 3.1. Access to operators platform
- 3.2. Operators seat
- 3.3. Instructional seat
- 3.4. Forward controls
- 3.5. Righthand side controls
- 3.6. Rearward controls
- 3.7. Overhead controls
- 3.8. Exterior controls
- 3.9. Instrument cluster
- 4. OPERATING INSTRUCTIONS
- 4.1. Commissioning the unit
- 4.2. Starting the unit
- 4.3. Stopping the unit
- 4.4. Moving the unit
- 4.5. Parking the unit
- 5. TRANSPORT OPERATIONS
- 5.1. Road transport
- 5.2. Shipping transport
- 5.3. Recovery transport
- 6. WORKING OPERATIONS
- 6.1. General information
- 6.2. REAR POWER TAKEOFF (PTO)
- 6.3. THREEPOINT HITCH
- 6.4. DRAWBARS AND TOWING ATTACHMENTS
- 6.5. TRAILER BRAKE COUPLER
- 6.6. AUXILIARY POWER CONNECTIONS
- 6.7. HYDRAULIC REMOTE CONTROL VALVES
- 6.8. BALLASTING THE TRACTOR
- 6.9. FRONT AND REAR AXLE
- 7. MAINTENANCE
- 7.1. General information
- 7.2. Maintenance planning
- 7.3. At warning message display
- 7.4. Every 10 hours or daily
- 7.5. Every 50 hours
- 7.6. First 100 hours
- 7.7. Every 600 hours
- 7.8. Every 600 hours or yearly
- 7.9. Every 1000 hours or yearly
- 7.10. Every 1200 hours
- 7.11. Every 1800 hours
- 7.12. Every 2400 hours
- 7.13. Every 3000 hours
- 7.14. As required
- 7.15. Fuse and relay locations
- 7.16. Storage
- 8. TROUBLESHOOTING
- 8.1. Fault code resolution
- 8.2. Alarm(s)
- 9. SPECIFICATIONS
- 9.1. Engine specifications
- 9.2. Power train and hydraulics
- 9.3. Lubricants and capacities
- 9.4. Speed charts PowerDrive transmission
- 9.5. Speed charts CVXDrive transmission
- 9.6. Vehicle dimensions and shipping weight
- 9.7. Maximum operating weight
- 10. ACCESSORIES
- 10.1. Farming system displays
- 10.2. Chemical tank mounting
- 10.3. General accessories
